Glass Hanging Clips come in a variety of styles, shapes, and surface finishes, allowing designers to coordinate hardware with the overall theme of the space. Common finishes include brushed stainless steel, polished chrome, matte black, satin nickel, and gold plating.Their primary function is to keep glass panels firmly in place while distributing the load evenly, reducing stress points that could cause cracks or structural instability.They are also easy to install and remove, making them a versatile solution for both temporary and permanent setups.
90° Precision Corner Splicing: Unlike generic corner clips with loose angle tolerance, this clip is pre-calibrated to 90° (±0.5°) to ensure gap-free glass-to-glass corner joints—reducing water leakage risk in shower enclosures by 60%.
45×45mm Compact L-Shaped Design: The symmetric small-profile structure saves 25% of corner space compared to 60mm-wide clips, making it perfect for small apartment bathrooms or boutique hotel guest room shower corners.
SUS304 Stainless Steel Long-Term Durability: The food-grade SUS304 material passes 240-hour salt-spray testing (no rust/discoloration), outperforming 201 stainless steel alternatives in humid bathroom environments.
Balanced Dual-Hole Fixing: The 22.5mm-spaced fixing holes distribute clamping force evenly across the glass corner, eliminating "local stress cracks" common in single-hole corner clips and enhancing glass stability by 40%.
Seamless System Integration: Pair with D&D’s Shower Cubicle System, Shower Door Knob, and Restroom Accessories to build cohesive corner frameless setups—enabling one-stop sourcing for renovation contractors.
50kg High Load for Corner Glass: Each clip supports up to 50kg (equivalent to 1m-span 8-10mm corner glass), eliminating the need for extra corner supports and cutting project material costs.
On two 8-10mm tempered glass panels (to be joined at 90°): Mark 15cm from top/bottom edges (apply masking tape to prevent scratches), then use a 90° ruler to align panel edges for a precise corner joint.
Fit Glass into Corner Clip Slots:
Slide each glass panel into one of the clip’s L-shaped slots—ensure panels sit flush with the clip’s inner 90° edge (no gaps between glass and clip).
Secure the Corner Clip:
Hold the clip (with glass inserted) in place; mark screw hole positions through the clip’s pre-drilled holes onto the glass.
Drill 2mm pilot holes (depth: 10mm) into the glass, then tighten screws to 3N·m torque (avoid over-tightening to prevent glass cracking).
Verify Corner Stability:
Use a 90° ruler to confirm the right-angle corner joint; gently apply lateral force to the corner glass to check for no movement.
Add 1 clip per 50cm panel length for extra-large 1.2m-span corner glass sections (if needed).
Application Scenarios
The DDGC011 90° Corner Glass Clip excels in space-efficient corner layouts, integrating with D&D’s shower hardware ecosystem:
Boutique Hotel Guest Room Corner ShowersUrban Apartment Small Bathroom Corner PartitionsHospital Patient Accessible Corner Shower RoomsGym Locker Room Corner Glass DividersOffice Building Restroom Corner Glass Enclosures
In boutique hotels, it creates sleek corner shower enclosures (paired with Shower Pull Handles for luxury functionality); in urban apartments, its compact design maximizes limited bathroom space; in hospitals, the easy-clean mirror finish aligns with sanitization protocols, while SUS304 material resists corrosion from cleaning chemicals.
Customization Options
Material Upgrade: SUS316 Stainless Steel (for extreme coastal humidity or chemical-exposed laboratory restrooms).
Surface Finish Customization: Brushed Stainless Steel, Matte Black PVD, or Bronze-Toned PVD (to match Restroom Accessories or project branding).
Glass Slot Customization: 10-12mm slot width (for thicker non-standard corner glass, available on custom order).
OEM Branding & Packaging: Laser-engraved client logos on clip bodies, custom branded boxes (ideal for apartment complex suppliers or corner shower project distributors).
Production Process & Quality Control
Material Sourcing & Verification: SUS304 stainless steel sheets are tested via optical emission spectrometry (OES) to confirm purity meets glass door hardware structural and hygiene standards.
CNC Precision Machining: Clips are shaped to 0.02mm dimensional tolerance (45×45mm) to ensure 90° angle accuracy and 8-10mm slot precision for gap-free corner splicing.
Surface Treatment & Plating: Clips undergo electroplating (mirror finish) + 72-hour baking to enhance finish adhesion and corrosion resistance.
100% Functional Testing: Every unit undergoes 50kg load testing (24h), 240-hour salt-spray testing, and 90° angle verification—failed units are discarded immediately.
Final Inspection & Packaging: Clips are checked for surface consistency, slot width, and corner stability; only passing products are packaged (custom packaging available via OEM).
