WL2000 Automatic Butyl Extruder Machine
WL2000 Hot Melt Butyl Extruder machine with the function to seal rectangle and curve shape aluminum spacer.Machine can seal to 6-27mm aluminum spacer bar.Our Hot Melt Butyl Extruder Machine with 4 variable frequency adjustable processing speed, maximum speed: 28m/min and independent parameter memory, the corresponding parameters change automatically after adjust the speed, no need to adjust again.
1 Butyl extruder can process frames from 6-25mm width.
2 The feeding nozzles can be positioned automatic to deliver uniform sealing.
3 Pneumatic operation of butyl process is controlled by a PLC that electronically regulates the temperature of the butyl heaters.
4 A timer enables the preheating of butyl ahead of the start of operation.
5 The height adjustment is available according to the frame size.
6 The nozzle width shall be controlled by the pneumatic and hydraulic parallel method.
7 Conveyor speed can be adjusted with 5 conveyor speed.
8 Possible to control the length of butyl application and monitoring current production quantity on the touch screen.
9 Adopt Germany pneumatic pump,brand Maximator.
10 The machine has sealant shortage alarm system.
11 The maximum amount of glue is 14L.
Kindly note:
Before you buy the machine, please make sure then tell me your local power supply,then we can make the right according to your true voltage.
| Max glass size | 2500x3500mm |
| Min glass size | 250*250mm |
| Glass thickness | 3-19mm |
| Sealing speed | 5-30m/min |
| Spacer width | 6-25mm |
| Conveyor speed | 0-25m/min |
| Power supply | 3.75KW |
| Dimension | 3000(L)x600(W)x950(H)mm |
| Butyl volume | 14L |
Main components :
| No. | Name | Brand | Country |
| 1 | Low-voltage electrical component | SCHNEIDER | FRANCE |
| 2 | PLC | OMRON | JAPAN |
| 3 | Touch screen | OMRON | JAPAN |
| 4 | Transducer | OMRON | JAPAN |
| 5 | Temperature controller | OMRON | JAPAN |
| 6 | Approach switch | AUTONIC | KOREA |
| 7 | Photoelectric switch | AUTONICS | KOREA |
| 8 | Pneumatic pump | MAXIMOTOR | GERMANY |
| 9 | Hydraulic solenoid valve | AUTONICS | KOREA |
| 10 | Air parts | AIRTAC | TAIWAN |
| 11 | Air-hydraulic pressure cylinder | HUAYING | CHINA |
| 12 | Motor | DPG |
CHINA |
Our main components are all used world-renowned brands ensure that equipment operates more stably.
Other Items Of our company:
1 Hot Melt Glue Sealing Machine
2 Automatic Desiccant Filling Machine
3 Manual Desiccant Filling Machine
4 Insulating Glass Sealing Robot
5 Automatic Aluminum Spacer Bar Bending Machine
