Dongfeng Tianjin small three-axle oil tanker

Dongfeng Tianjin small three-axle oil tanker

4 month ago

7 0

Hubei Ocean Automobile Industry Co., Ltd.

 7 month year

Product details

Chassis configuration: Dongfeng Tianjin chassis, wheelbase 1995+5000, cab D530 row half standard roof, engine B6.2NS6B245,

aftertreatment U type, transmission DC7J100TA, gear ratio 8.4/0.786, front and rear axle 6T10 T single reduction,

leaf spring 3/-, frame 250×80×7+4, fuel tank aluminum 280L, final reduction ratio 4.875, tire 295/80R22.5 18PR,

power take-off interface, air conditioning, PTO interface, no PTO device, There are driving recorders, exhaust pipe front,

front disc brakes, front tire burst emergency, ECU speed limit, dangerous goods warning lights,

EBS(electro-pneumatic braking system), FCWS/LDWS (front collision/lane departure warning),

TPMS (front axle single tire pressure monitoring), ESC(anti-rollover system), exhaust braking.

Top Configuration: Effective tank volume: 21.5 cubic meters, 5182 aluminum alloy plate, tank 6 thick, head 6 thick,

partition 6 thick, single bin, tank top two European standard tank mouth, 1 new regulation intelligent closing submarine valve,

1 set of lower oil (Oil unloading valve, oil vapor recovery, anti-overflow probe rod, anti-static reel),

with 80-60 special oil pump (pump in and pump out) Rear ladder, manual guardrail, toolbox, rear bumper,

side guard rail are aluminum alloy plates, manufactured according to the new standard of 2020, standard for other manufacturers,

tank inspection report, chassis certificate, vehicle license, household invoice

Flaw detection process All main welds of the tank body shall be operated in strict accordance with the flaw detection process

(double gun butt welding, automatic welding of the forehead and neck annular seam cover,

automatic welding of the head annular seam cover), and flaw detection (X-ray detection) shall be carried out according to

the flaw detection proportion specified in GB18564.1-2019 standard.

Aluminum alloy tank density is small, light weight, relatively low center of gravity is safer, more fuel-efficient,

aluminum alloy tank does not rust, no pollution to oil.
