Naipu Pump produce the slurry pump which is the cantilever, horizontal and centrifugal ones. Corrosion Slurry Pumps are designed for a wide range of erosive and corrosive applications. Coal Mine Slurry Pump are generally used for slurries containing high concentrations of erosive solids or where an extremely robust and heady duty pump is required.
Horizontal Centrifugal Pump, Coal Mine Slurry Pump, Corrosion Slurry Pump, Slurry Pump Impeller, Pump Spare Parts, OEM Slurry Pump, OEM Pump Parts.
Index
Value
Products Name
12/10 ST-AH Horizontal Centrifugal Pump
Inlet Dia (mm)
300
Outlet Dia (mm)
250
Flow (m3/h)
936-1980
Head (m)
7-68
Max Power(kw)
560
Material
High Chrome A05
Drive Type
CV / ZVz / CRz/ DCz
Drive Engine
Motor or Diesel
Seal Type
Packing Seal , Expeller Seal, Mechanical Seal
Payment Term
TT , LC, or Negotiate
Original
ShiJiaZhuang , Hebei China
Supply Range
Slurry Pump , Motor , Base Plate,Guard, v-belt , Pulley
Weight
4318 kg
|
Type |
Max Power (Kw) |
Clear Water Performance |
Impeller |
|||||
|
|
|
Capacity /m³/hr |
Head /m |
Speed/rpm |
Max
Efficiency |
NPSH /m |
Nos |
Diameter |
|
1.5/1 B-AH |
15 |
12.6-28.8 |
6-68 |
1200-3800 |
40 |
2-4 |
5 |
152 |
|
2/1.5 B-AH |
15 |
32.4-72 |
6-58 |
1200-3200 |
45 |
3.5-8 |
5 |
184 |
|
3/2 C-AH |
30 |
39.6-86.4 |
12-64 |
1300-2700 |
55 |
4-6 |
5 |
214 |
|
4/3 C-AH |
30 |
86.4-198 |
9-52 |
1000-2200 |
71 |
4-6 |
5 |
245 |
|
6/4 D-AH |
60 |
162-360 |
12-56 |
800-1550 |
65 |
5-8 |
5 |
365 |
|
8/6 E-AH |
300 |
360-828 |
10-61 |
500-1140 |
72 |
2-9 |
5 |
510 |
|
10/8 F-AH |
560 |
612-1368 |
11-61 |
400-850 |
71 |
4-10 |
5 |
686 |
|
12/10 ST-AH |
560 |
936-1980 |
7-68 |
300-800 |
82 |
6 |
5 |
762 |
|
14/12 ST-AH |
560 |
1260-2772 |
13-63 |
300-600 |
77 |
3-10 |
5 |
965 |
|
16/14 TU-AH |
1200 |
1368-3060 |
11-63 |
250-550 |
79 |
4-10 |
5 |
1067 |
|
20/18 TU-AH |
1200 |
2520-5400 |
13-57 |
200-400 |
85 |
5-10 |
5 |
1370 |
