Product details

Toyota Warehouse Forklift - BT Reflex 1.8 Ton for Optimal Performance

The Toyota BT reflex forklift RRE180 is positioned in the high-end warehousing and logistics market and is suitable for warehousing environments with high requirements, such as large warehouses, logistics centers, and supermarket distribution centers. In different operation scenarios, drivers can quickly adjust the driving speed and lifting height of the forklift through the touch screen according to actual needs to achieve precise operation.

Technical Parameters

Rated load: 1800 kilograms, with a load center distance of 600 millimeters.

External dimensions: The overall width is 1270 millimeters, the turning radius is 1717 millimeters, the height of the overhead guard is 2261 millimeters, and the length to the vertical surface of the fork is 1344 millimeters.

Lifting height: It can reach 6 meters under the standard configuration (higher masts can be optionally equipped, such as 8.5 meters), which is suitable for multi-layer shelf scenarios.

Performance parameters: The driving speed (with/without load) is 14 kilometers per hour, the lifting speed (with/without load) is 0.35 meters per second and 0.7 meters per second, respectively, and the lowering speed (with load) is 0.55 meters per second.

Core Advantages of Toyota Forklift

1. Precise Control and Stability

The hydraulic lifting/tilting speed of the RRE180 can be linearly adjusted according to the stroke of the operating lever, achieving positioning accuracy at the millimeter level.

The sunken layout of its battery pack lowers the center of gravity of the whole vehicle. Combined with the full hydraulic steering system, it improves the driving stability under full load.

2. Safety Protection System

The Toyota BT Forklift RRE180 is standardly equipped with an OPS operator presence sensing system, an emergency power-off button, and an overload protection device. The overhead guard of the forklift complies with the ISO 6055 standard, and its impact resistance reaches 1 ton. The anti-collision buffer strips on the forks reduce accidental collision damage.

3. Maintenance Friendliness

Core components such as the motor and controller can be quickly disassembled, and the average repair time (MTTR) is shortened to less than 30 minutes. Parameters such as the battery SOC and motor temperature are monitored in real-time through the CAN bus, and the fault codes can be traced back to specific components.

Applicable Scenarios

1. High-density Warehousing

Narrow aisle warehouses with an aisle width ≤ 3.5 meters, such as cold chain logistics and pharmaceutical distribution centers.

2. Multi-layer Shelf Operations

The lifting height is≥ 6 meters, which is suitable for the access of pallets in stereoscopic warehouses.

3. High-frequency Handling

E-commerce sorting centers and automotive parts factories with an average daily operation frequency of > 200 times.
