Tjer135 37kN Radar Leveling Electric Actuator1

2 month ago

12 0

Suzhou Tongjin Precision Industry Joint-stock Co.,Ltd

 3 month year

Product details

Radar Leveling Electric Actuator, Heavy Duty Electric Actuator, and High Load Electric Actuator are advanced motion control solutions designed for demanding industrial applications. These electric actuators combine precision engineering with robust construction to deliver reliable performance in challenging environments. Whether used in automation systems, material handling, or heavy machinery, these actuators ensure smooth operation, high efficiency, and long-term durability. Each unit is engineered to handle substantial forces and maintain accurate positioning, making them ideal for industries that require consistent and precise movement control.

Screw specification	5010
Standard motor rated power KW	5
Motor rated torque N·m	15.8
Rated motor speed r/min	3000
Reduction ratio	7
Standard motor rated thrust kN	56
Standard motor rated speed mm/s	71
Repeated positioning accuracy mm	±0.01/±0.02
Maximum effective travel mm	200
Maximum load thrust kN	60
Maximum expansion speed mm/s	500

Tjer135 37kN Radar Leveling Electric Actuator
Our company has successfully independently developed independent products such as Tongjin brand servo electric cylinders, intelligent servo press fit machines, Linear Electric Actors, Heavy Duty Electric Cylinders, Servo Press Machines, etc., combined with six joint robots to achieve automated, safe, and unmanned intelligent assembly green unmanned production lines, providing a one-stop solution for intelligent assembly automation systems in factories.
