STRONG-GR-2512 infrared pyrometer technical parameters
|
Model |
STRONG-GR-2512 |
|
Measuring Range |
250 degC～1200 degC |
|
Detector |
InGaAs/InGaAs（Laminated InGaAs） |
|
1-color Wavelength |
1.7μm |
|
2-color Wavelength |
Wavelength1：（0.9～1.7）μm Wavelength 2：1.7μm |
|
Main Applications |
Hot rolled steel, wire rod, Non-ferrous metal processing, induction heating, galvanized wire |
|
Distance Coefficient |
30：1 |
|
Measuring Distance |
Standard focal length：adjustable from 0.35m to infinite；near focal length：0.15m～0.5m |
|
Measuring Accuracy |
±0.5%T（T is measured value） |
|
Resolution |
0.1 degC |
|
Repeat Accuracy |
±2 degC |
|
1-color Coefficient |
0.100～1.100，adjustable in 0.001 increment |
|
2-color Coefficient |
0.850～1.150，adjustable in 0.001 increment |
|
Response Time |
Fastest 5ms，5ms-99.99s adjustable |
|
Signal processing |
Peak value, valley value, average temperature value; Ambient temperature too high/low alarm; switch between one-color and two-color mode; power down protection. |
|
Output
|
Group1: Multiple analog outputs 16bit（4mA～20mA，0mA～20mA，0V～5V，0V～10V, switchable), output resolution 16bit, accurate to 0.1 degC, maximum current loop output load 600Ω，maximum current output load 10mA |
|
Gourp2: Analog outputs 4mA～20mA，resolution 16bit, accurate to 0.1 degC, maximum current loop output load 600Ω |
|
|
Alarms output: upper or lower temperature limit alarm；PhotoMOS relay (infinite service life) on resistance≤2Ω, maximum allowed voltage: AC60V or DC60V; maximum allowed current: 120mA; response time: 2ms |
|
|
PNP level output（current output 100mA，with overload protection.） |
|
|
RS485 output, with functions of parameters modification, data logging and inquiry |
|
|
Display Mode |
Industrial-grade self-luminous OLED display screen |
|
Power Input |
DC(20～30)V, with over voltage, over current and short circuit protection; Power consumption: 5W (24V@200mA) with built-in EMI wave filter, resistance to pulse group’s Interference: 2500VDC |
|
Warm up time |
With built-in 40 degC constant temperature heater, start temperature measurement within 10mins after power on. Assembled whole-process temperature compensation, temperature measurement accuracy is nearly unaffected by ambient temperature. |
|
Aiming Method |
Green visible aiming laser, eyepiece aiming,video aiming choose 1 |
|
Port |
Imported sealed plug and 12-core high-temperature shielded cable |
|
Operating Environment |
No water cooling：-20 degC～+60 degC，air purge pressure: 0.1MPa，flow rate: 6L/ min With water cooling：-20 degC～+200 degC，water cooling pressure: 0.2MPa，flow rate: 2L/min |
|
Protection Level |
IP65 |
