| Combination Properties |
Standard |
Unit |
Test Data |
| Melting temperature |
ISO 11357-3 |
°C |
145 |
| Coefficient of linear thermal expansion |
DIN 53752 |
10-6 / K |
80 |
| Service temperature, long term |
Average |
°C |
70 |
| Service temperature, short term (max.) |
Average |
°C |
85 |
| Heat deflection temperature |
ISO 75 |
°C |
75 |
| Dielectric constant (100Hz) |
IEC 60250 |
|
3.3/- |
| Dielectric strenght |
IEC 60243 |
kV / mm |
20 |
| Surface resistivity |
IEC 60093 |
Ω |
1014 |
| Volume resistivity |
IEC 60093 |
Ω˙cm |
1013 |
Product advantages
- Excellent comprehensive mechanical properties: It has high rigidity, high impact resistance and good wear resistance, suitable for scenes with high requirements for structural strength and durability, and is better than single polymers (such as PP, PVC).
- Strong processing flexibility: It supports a variety of molding processes (thermoforming, injection molding, machining), and can manufacture parts with complex shapes; it has diversified surface treatments (printing, electroplating) to meet high decorative requirements.
- Balance between weather resistance and decorativeness: By adding UV stabilizers and masterbatches, it can achieve long-term outdoor use and personalized appearance design (such as advertising panels, home appliance housings).
- Economical and environmentally friendly: The material cost is lower than that of engineering plastics (such as PC, POM), and the waste can be recycled (recycling rate> 85%), which is in line with the concept of sustainable manufacturing.
Specific application areas and components
Electronic device housing: battery cover, back cover or bracket for mobile phones, tablets and laptops. The high rigidity of ABS sheet can protect internal components, and the surface gloss and electroplating performance can enhance the product texture (such as high-end home appliance control panel).
Home appliance housing and components: refrigerator door panels, washing machine control panels, air conditioner outlet grilles, etc. ABS's impact resistance and chemical resistance can adapt to frequent use and contact with detergents in the home environment.
Toys and game controllers: children's toy housings or game controller bodies. ABS's non-toxicity (compliant with EN71, ASTM F963) and high impact resistance ensure safety and durability.
Automotive interior parts: dashboard skeleton, door panel interior, air conditioner outlet, central console, etc. ABS sheet can be molded into complex structures through injection molding, and the surface can be coated with soft materials (such as PU skin) to enhance the touch.
Railway transit protective cover: Equipment protective cover in subway and high-speed rail carriages (such as emergency call button boxes and lighting fixture housings). ABS's high rigidity can resist vibration and minor collisions, and its weather resistance meets the needs of long-term outdoor use.
Automotive exterior parts: Rearview mirror housings, bumper trims, etc. (flame retardants and UV stabilizers need to be added
Advertising display boards and signboards: Advertising display boards used in shopping malls, subway stations, and airports. High-definition patterns can be printed on the surface of ABS sheets. The weather resistance (after UV stabilization) is better than PVC, and it will not deform or fade after long-term outdoor use.
Soundproof barriers and anti-collision panels: Soundproof wall panels along highways and railways. ABS's high toughness can absorb impact energy and reduce secondary injuries in traffic accidents; its low density reduces structural loads.
Indoor decorative partitions: Partition wall panels for hospitals, laboratories, and offices. ABS's easy-to-clean and moisture-proof properties meet hygiene and safety requirements. Surface coating can improve wear resistance and aesthetics.
Protective covers and safety fences: Safety protective covers for machine tools, automation equipment or housings of laboratory instruments. ABS's high impact resistance can prevent tool splashes or accidental collisions from damaging internal components.
Instrument panels and consoles: Operating panels or consoles for industrial equipment (such as injection molding machines and packaging machines). ABS's chemical resistance can resist oil and detergent corrosion, and the surface can be screen-printed with logos.
Guide rail supports and structural components: Guide rail sliders or support frames for light-loaded mechanical structures (such as 3D printers and small conveyors). ABS's low friction coefficient (0.3-0.4) and wear resistance are better than PP and HDPE.
