Dimension: 130*55* 34mm
Weight: ≤350g
Output power: 1W/5W
Channel capacity: 512
Side button : 2
2.4 inch color LCD display
Functions
Package include
| Specification | |
|---|---|
| Power Requirements | 7.4V |
| Battery Capacity | Approx. 2600mAh (Standard version) |
| Dimensions (without antenna) | 55 x 34 x 130 mm |
| Weight | ≤ 350g |
| Water and Dust Resistance | IP67 |
| Explosion-Proof Class(Optional) | Optional Ex ib IC T4 Gb; Ex ib IC T130°C Db |
| Display | 2.4-inch LCD |
| Frequency Range | 136-174MHz/ 350-400MHz/400~470 MHz |
| Channel Capacity | 512 |
| Channel Spacing | 6.25 kHz / 12.5 kHz / 25 kHz |
| Frequency Stability | ±1 ppm |
| Analog Sensitivity | 0.22 μV (FM @ 12 dB SINAD) |
| 0.18 μV (typ.) (FM @ 12 dB SINAD) | |
| 0.3 μV (FM 20 dB SINAD) | |
| Digital Sensitivity | 0.30 μV (typ.) (@ 5% BER) |
| Intermodulation | 60 dB @ 12.5 kHz; 60 dB @ 25 kHz |
| Adjacent Channel Selectivity | TIA603C: ≥55 dB @ 12.5 kHz |
| ETSI: ≥55 dB @ 12.5 kHz | |
| Output Power | Minimum: ≤1W; Maximum: ≤5W |
| Audio Distortion | <2% |
| Digital Protocol | ETSI TS 102 361-1,-2,-3 |
| Vocoder | AMBE+2 IN VOC |
| Frequency Modulation | 16K0F3E @ 25 kHz |
| 8K0F3E @ 12.5 kHz | |
| 4K00F1D @ 6.25 kHz | |
| Modulation Limitation | 2.5 kHz @ 12.5 kHz |
| 5.0 kHz @ 25 kHz | |
| 4FSK Modulation | ≤8.5 kHz |
| Operating Temperature | -25°C to +55°C |
| Standby Temperature | -40°C to +70°C |
