POM-C Sheet 8mm 12mm Polyoxymethylene Sheet

White POM (Polyoxymethylene) sheet is a semi-crystalline thermoplastic engineering plastic made by copolymerization (POM-C) process, with excellent mechanical strength, wear resistance, dimensional stability and chemical corrosion resistance. White POM C sheet uses high-purity resin raw materials, and adds stabilizers, anti-UV agents and white pigments to ensure that the material maintains color stability and performance consistency in long-term use.

Production process:

Extrusion molding: Suitable for standard thickness (1-100mm) sheets, with uniform crystal structure and stable mechanical properties.

Casting molding: Used for ultra-thick sheets (more than 100mm), with lower internal stress, suitable for high-precision processing.

Surface treatment: Glossy, frosted or anti-static coating can be provided to meet different application requirements.

Appearance characteristics:

Color: Pure white (customizable ivory white, milky white, etc.).

Surface: Smooth and flat, without bubbles, cracks or impurities.

Transparency: Translucent to opaque (depending on thickness).

Core advantages

Wear resistance:

The friction coefficient is lower than that of nylon (PA) and polycarbonate (PC), and the self-lubricating property reduces the need for additional lubrication, which is suitable for oil-free environments (such as food machinery).

Dimensional stability:

The water absorption rate is only 0.2% (1.5% for nylon), and it is almost not deformed in a humid environment, which is suitable for precision parts (such as clock gears, optical instrument brackets).

Processability:

It can be turned, milled, drilled, and laser cut, and a smooth surface (Ra＜1.6μm) can be obtained after processing without post-treatment.

Thermoforming temperature range is wide (160-190°C), which is suitable for complex structure molding.

Lightweight metal replacement:

The density is 1.41-1.42 g/cm³ (only 1/2 of aluminum alloy), which can reduce the inertia of moving parts and improve the energy efficiency of equipment.

pom c sheets

Application areas

Precision machinery and automation

Typical components:

Gears (module 0.5-2mm micro gears, planetary gears).

Bearings (unlubricated bearings, linear guide sliders).

Cams, couplings, valve seats.

Advantages:

Low noise operation (noise reduction of more than 30% compared to metal gears).

Fatigue resistance > 10⁷ cycles (far exceeding ordinary plastics).

Automobile industry

Typical components:

Fuel system: fuel pump gears, fuel tank floats.

Interior parts: door lock buckles, seat adjustment racks.

Engine periphery: throttle body parts, cooling fan brackets.

Advantages:

Oil resistance (expansion rate <1% after long-term immersion in gasoline).

Significant weight reduction effect (replacing metal can reduce weight by 30%).

Electronics and electrical appliances

Typical components:

Insulating components: circuit breaker housing, relay base.

Structural parts: printer rollers, scanner guides.

Advantages:

Flame retardant grade can reach UL94 HB (V-0 grade modified grades are optional).

Arc resistance (CTI＞600V).

Medical and food equipment

Typical parts:

Medical: insulin pen gears, endoscope rotating parts.

Food: filling valves, conveyor belt wear strips.

Advantages:

Can be sterilized by gamma rays or ethylene oxide.

Complies with EU 10/2011 food contact regulations.

polyoxymethylene sheet

pom material

White POM sheet is the "steel" of engineering plastics and is irreplaceable in scenarios that require high strength, wear resistance, precision and stability. From micron-level gears to automotive fuel systems, its performance advantages have been verified by decades of industry. In the future, with the advancement of modification technology, POM will expand its application space in emerging fields such as aerospace and new energy.
