LINGWO PUR9670 Waterproof Compound for Cable Wires

Product Introduction

LINGWO PUR9670 Waterproof Compound is a high-performance sealing material formulated from imported polymer materials, including polybutylene. It is designed to provide long-lasting waterproof protection for cables, wires, and other critical infrastructure.

Key Parameters

Parameter	Technical Requirement
Appearance	Homogeneous, free of dust, metal particles, or impurities
Acid Value	≤ 0.5 mgKOH/g
Color Stability (130°C, 120H)	≤ 2.5%
Oxidation Induction Period (190°C)	≥ 10 min
Dropping Point	105 ± 5℃
Flash Point	≥ 200°C
Engler Viscosity (120°C)	≥ 10E
Oil Separation (50°C, 24H)	≤ 5
Low-Temperature Brittleness (-10°C, 1H)	≤ 2/10pcs
Water Resistance (168H)	No disintegration

Key Advantages

Superior Lubrication: Maintains lubrication even in humid environments.
Excellent Waterproofing: Provides robust sealing and resistance to water erosion.
High Pressure Resistance: Non-curing, non-dissolving, and non-dispersing.
Temperature & Chemical Stability: Performs reliably across extreme temperatures and harsh chemical conditions.
Material Compatibility: Compatible with plastics and metals.
Eco-Friendly: Non-toxic, odorless, and fully compliant with environmental standards.

Applications

Submarine cables, fiber optics, and coaxial cables.
Building waterproofing and security systems.
Industrial cable protection in harsh environments.

Q&A

Q1: How is the compound applied?

A: Heat the compound to 120°C–170°C while stirring continuously. Apply evenly using specialized equipment and molds, then cover with an outer protective sheath.

Q2: How to clean the application equipment?

A: For tanks with drainage systems:

Heat to 150°C–180°C.
Drain the compound once stable.
Clean residual compound with ethyl acetate after cooling.
Alternative: Scrape off residue with a metal blade, wipe with a cloth, then clean with ethyl acetate.

Q3: What are the storage conditions?

A: Store at room temperature in a ventilated, dry area away from direct sunlight. Avoid rain and intense heat during transport.

Q4: What is the shelf life?

A: 12 months

Company Introduction

FAQ

Q1: Are you trading company or manufacturer?

A1: We are factory with 13+ years of experience,and can provide you direct prices.

Q2: Can I be your agent?

A2: Sure,we are looking for agent all over the world.

Q3: Can I get a sample before mass production?

A3: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q4: What can I buy from you?

A4: We are a manufacturer of industrial adhesive products,the main products are: Epoxy adhesive, liquid PUR, hot melt adhesive, UV adhesive, instant adhesive, acrylic structural adhesive, treatment agent, etc.

Q5: How can we guarantee quality?

A5: Always a pre-production sample before mass production;always final inspection before shipment.

Q6: Why should you buy from us not from other suppliers?

A6: Factory prices,on-time deliveries,assured quality,good service,before and after sales.
