Product details

Customizable Aluminum Slide Windows in Dark Tinted Style

In modern architectural design, doors and Windows are not only the hub of spatial connectivity, but also the integration of energy saving, comfort and aesthetics. As a model of innovation in the Aluminum Alloy Windows industry, bronze dark aluminum alloy sliding Windows with its excellent performance and elegant appearance are becoming the first choice for owners pursuing high quality life. This article will analyze how this product redefines the standard of modern home doors and Windows through the three core advantages of energy saving, heat insulation and sound insulation.

Product Highlights:

Energy-saving Technological Innovation

Using the broken bridge aluminum profile and multi-cavity structure design, Aluminum Sliding Windows effectively block indoor and outdoor heat conduction. With double-layer hollow Low-E glass, it can reduce the heat loss in winter by more than 30%, block ultraviolet radiation in summer by 90%, significantly reduce the energy consumption of air conditioning, and help create a low-carbon energy-saving space.

Triple Insulation System

Broken bridge aluminum profile: PA66 nylon heat insulation strip forms a physical heat insulation barrier

Insulating glass: 12mm air layer with argon filling technology

Multi-lock seal: EPDM rubber strip achieves 360° sealing without dead Angle

Through the international standard heat conduction coefficient test (U value ≤1.8W/(m² · K)), to ensure that the indoor temperature is constant throughout the year.

Professional Sound Insulation Solutions

6mm+12mm+6mm tempered laminated glass combination, with double sealing process, can effectively block the external noise above 60 decibels. Whether it is the noise of the traffic road or the sound of the neighborhood life, it can achieve the ideal sound insulation effect and create a quiet home environment.

SERIES	Wendou-85 Thermal Break Sliding And Tilt Window
Trackwindth	85mm
Profile	6063-T5 Thermal Break Aluminum Profile
Thickness	1.8mm Aluminium Thickness
Glass	Automotive Grade Tempered GlassDouble / Triple Tempered Glass
Middle Hollow	Double Glazing Tempered 5mm+22Ar+5mm
Hardware	Germany brand/Chinese brand/American brand
Surface Treatment	Powder Coating, AnodizedWooden Grain,PVDF Coating
Opening Mode	Sliding And Tilt

Design Details

Surface treatment: Using Akzonobel electrostatic powder spraying process, the bronze dark coating is durable and has anti-ultraviolet discoloration performance for more than 10 years

Hardware system: HOPPE handle and multi-lock linkage device imported from Germany, smooth opening and closing, bearing up to 150kg

Drainage design: Hidden drainage system combined with isobaric cavity structure to ensure zero leakage of rainwater

Safety configuration: Standard 304 stainless steel screen window, anti-mosquito anti-theft dual effect

Application Scenario

Suitable for all types of residential, villa, apartment and commercial space, especially recommended:

Street front house and high-rise apartment

Noise sensitive study/bedroom

Sun room and glass terrace renovation

Constant temperature and humidity demand smart home system

Bronze dark aluminum sliding window with technology to enable life, the three core performance of energy saving, heat insulation, sound insulation perfect integration. Its minimalist lines and elegant colors not only enhance the aesthetics of the building facade, but also create a comfortable, safe and sustainable living experience for users through the precision process of German industry standards. Contact us today for customized solutions that make quality Aluminum Glass Siliding Windows the finishing touch of your ideal life.
