Cooling Pad is a kind of special Kraft paper honey comb structure material, cooling pad working principle is "water evaporation absorbs heat" this natural physical phenomenon. Under the action of gravity the water from above of wet curtain in corrugated fiber surface to be the water film formation. When rapid air flowing through the wet curtain water can absorb heat from the air water film. So that after wet curtain reduces the heat air temperature to achieve the purpose of cooling. The cooling pad production line is the equipment which products the cooling pad, main parts contain spraying resin machine, cutting machine, corrugated machine, lifting platform, glue machine, heating oven, sawing machine, electrical control box and other accessories. The poultry cooling cell pad production line is an assembly line air cooler pad line can install one line but also can install different place is flexible.
Cooling pad production line main parts parameters
Shandong Kunzheng evaporative cooling pad production line has 8 main parts, spraying resin machine, cutting machine, corrugated machine, lifting platform, glue machine, heating oven, sawing machine, electrical control box and other accessories.
Spraying resin machine:
|
Dimension |
3500*1500*3000mm |
|
Heating power |
120kw |
|
Voltage |
380V |
|
Motor power |
1.1kw |
Cutting machine:
|
Dimension |
3500*600*1300mm |
|
Heating power |
24kw |
|
Voltage |
380V |
|
Motor power |
2.2kw |
Corrugated machine:
|
Dimension |
1800*1500*1100mm |
|
Voltage |
220V |
|
Power |
1.1kw |
Lifting platform:
|
Dimension |
2400*450mm |
|
Maximum height |
1000mm |
|
Voltage |
380V |
Glue machine:
|
Dimension |
3400*450*1000mm |
|
Voltage |
380V |
|
Power |
1.5kw |
Heating oven:
|
Dimension |
10020*3500*2000mm |
|
Heating power |
120kw |
|
Voltage |
380V |
|
Motor power |
4kw |
Sawing machine:
|
Dimension |
5500*3000*2200mm |
|
Voltage |
380V |
|
Power |
2.2kw |
Technical control box:
|
Dimension |
800*450*1800mm |
|
Voltage |
380V |
|
Phase |
3 phase/ 4 wire |
Cooling pad can be very effective to improve the workshop environment of high temperature with hot air, water wet corrosion-resistant evaporative cooling pad can make the plant temperature declines quickly and keep the temperature at 30 ℃. This is the most comfortable working environment for the human body. Ventilation equipment can improve employees' work efficiency and keep the high quality of the product. The paper pad production line has the characteristics of high efficiency, energy saving and environmental protection. The main parts can be flexibly connected, cellulose cooling pad can be combined together and divided for installation separately. Low requirement for production workshop, no need to build new factory. One set of production line can produce 3 specifications of water curtain paper, 7090/6090/5090 series of water curtain paper, as long as replaced the corrugating machine. The glue spraying machine runs efficiently and quickly with high production efficiency and uniformed glue application. The heating oven adopts three-way multi-tube design, cooling pad making machine can effectively utilize the heat energy, and can effectively and quickly dry cooling pad, with high thermal efficiency. The cutting machine is accurate and can adjust different sizes to meet different requirements of customers. The controllers are all copper wire, the resistance coefficient is lower and not easy to burn out.
Production line show:
Cooling pad ventilation and cooling effect can effectively solve the problem of high temperature and sultry, air pollution and obvious temperature effect. Both blow and draw the wind with the quality assurance, cooling pad is the best choice of ventilation for the greenhouse, poultry farm, industry factory and other cooling environment. Cooling pad is the most popular in the current industrial industry, its cooling environmental protection effect, energy-saving effect is better than any other cooling equipment. Corrugated cellulose outer frame is made of galvanized zinc-coating, Aluminum alloy and stainless steel.
Principle introduction
Wet curtain cooling mainly uses the physical principle that water absorbs heat from the air in the process of water evaporation to reduce air temperature. Used in combine with the negative pressure fan, cooling pad in airtight houses which is wall mounted in wall-window, negative pressure fan is installed at the other side. The exhaust fan takes out indoor air, produces negative pressure and forces outdoor air flowing through the surface of wet curtain, at the same time of ventilation cooling dust removal, honey comb pad makes a lot of calories in the air and reduce temperature 10 ℃. No matter how is summer hot but exhaust fan-cooling pad system always builds a comfortable working environment, cool and fresh. Also, extractor pad can improve the work efficiency.
Our company
Shandong Kunzheng Mechanical Equipment Technology Co,Ltd.
Add: No.3059, Pairs Road, Qingzhou Economic Development Zone, Shandong, China.
Kunzheng is a professional exhaust fan manufacture company, main products are large greenhouse livestock energy-saving fan, negative pressure fan, roof power ventilator and other ventilation cooling system; Coal - fired heat fan, wet curtain, cold fan, defecation machines and other products. Swung heavy hammer exhaust fan, centrifugal push-pull exhaust fan, fiber glass exhaust fan, cone fan, hanging cow house fan, water cooling fan, evaporative cooling pad as well. Kunzheng locates at beautiful QingZhou City, our company has strong technical force and professional team as backup. Our production sells to the whole world, such as Africa, India, Philippines, some European country and USA. Shandong Kunzheng is a professional temperature control equipment of animal husbandry manufacturer and technical greenhouse builders. It is locates in Qingzhou city, Shandong province,China. She has a modern industrial base of 4000 square meters. The corporation is set design, production, sale, installation and after sales in one line. It continuous selling for 9 years, has exported to more than 15 countries all over the world. During the period, it has been awarded the "China top ten best-selling brand", "Quality reliable products" and other honorary titles. Since its foundation, our company keeps living up to the belief of :" Most satisfying quality. Most favorable price. Most intimate service." We are doing everything to offer our customers with best cooperation experience. We promise that we will be responsible all the way to the end once our service begin.
Contact us
FAQ
Q1. How do we know which model is suitable for us?
A. Please contact with our salesman and let them know your request, they will recommend the correct model for you.
Q2. How long is the delivery time for order?
A. Generally 5 days, also it depends on the quantity of the order. It takes 7-10 days to finish a 40' container order.
Q3. What's the price term?
A. 30% deposit by T/T, 70% balance by T/T.
Q4. Can you request custom-made?
Yes, of course. We have own manufacture and factory, can product customized production.
