1 Year Warranty Low Displacement GH500 Orbital Motors1

1 Year Warranty Low Displacement GH500 Orbital Motors1

2 week ago

2 0

Jiangsu Guorui Hydraulic Machinery Co., Ltd.

 7 year year

Product details

Product Description

Iterminttent operation:the permissible values may occur for max.10% of every minute.
Peak load:the permissible values may occur for max.1% of every minute.
For speeds lower than given, consult factory or your regional manager.
1.Intermittent speed and intermittent pressure must not occur simultaneously.
2.Recommended filtration is per ISO clealiness code 20/16. A nominal fltration of 25 micron or better.
3.Recommend using a premium quality,anti-wear type mineral based hydraulic oil HLP(DIN51524)or HM(ISO6743/4)
If using synthetic fluids consult the factory for alternative seal materials.
4. Recommended minimum oil viscosity 13mm²/s[70SUS] at 50℃[122°F]
5. Recommended maximum system operating temperature is 82℃[180℉]
6.To assure optimum motor life fill with fluid prior to loading and run at moderate load and speed for 10-15 minutes.
