The use of Screw Pile dates back to the 1730s,when it was first used as a Ground Anchor system on a tidal lighthouse in England.From the early anti-anchorage pile to the later anti-compression pile,Ground Screw Piles has been widely used in power pylons,housing foundation,signal signs,street light foundation,and gradually applied in billboards,temporary meeting places,warehouse,school buildings,municipal facilities,transportation facilities and other independent buildings.
Photovoltaic solar power generation as a renewable clean energy,has been vigorously promoted in all countries in the world,can provide stable and reliable ground support for photovoltaic bracket pile,has also been widely used and repurchased by customers.
Material: S 235 carbon steel.
Length of the F Series Ground Screw: 550-6000 mm.
Steel Ground Screw's diameter:48 mm,68 mm,76 mm,89 mm,114 mm,according to clients' request.
Thickness of pipe:2.75 mm,3.00 mm,3.75 mm,4.00 mm.
Flange diameter:200 mm, thickness:8 mm or according to clients' request.
Common size of Galvanized Ground Screw as follow:
|
Diameter(mm) |
Thickness(mm) |
Length(mm) |
|
76 |
2.75 |
1000 |
|
76 |
2.75 |
1200 |
|
76 |
3.0 |
1200 |
|
76 |
3.0 |
1500 |
|
76 |
3.0 |
1800 |
|
89 |
3.0 |
1500 |
|
89 |
3.0 |
1800 |
|
89 |
3.0 |
2100 |
|
114 |
4.0 |
1800 |
|
114 |
4.0 |
2100 |
|
114 |
4.0 |
2500 |
If you are interested in the product, contact 2bvideo.com for more information for more information
