Reference standards |
GB/T 3984-2004 IEC 60110.1 |
|
Operating temperature range |
-40℃~+85℃ |
|
Capacitance range |
6.3μF |
|
Rated capacitance |
500 kVar |
|
Rated voltage |
700VAC |
|
Tolerance |
±10% |
|
Test voltage between terminals |
1.5UNAC 10s 3.0UNDC 10s at 25℃±5℃ |
|
Dissipation factor |
tgδ≤5×10-4 at 25℃±5℃ , 1kHz |
|
Insulation resistance |
R·C≥5000s，at 100VDC，25℃±5℃ , 60s |
|
Life expectancy |
100000hrs ( Un θhotspot ≤ 70℃) |
If you are interested in the product, contact 2bvideo.com for more information for more information
