F11 is a bent-axis, fixed displacement motor/pump. It can be used in numerous applications in both open and closed loop circuits.
F11-005 F11-006 F11-010 F11-012 F11-014 F11-019 Parker P11 Motor Pump.
F12-110-Ms-Sv-S-000-0000-P0
The F11 series is available in sizes 5, 6, 10, 12, 14 and 19 cc.
F11 Features
• Max intermittent pressure up to 420 bar and continuous operating pressure up to 350 bar
• Thanks to low weight pistons and a compact design of the rotating parts, the F11 tolerates very high speeds, up to 14000 rpm
• CETOP, ISO, SAW and SAE versions
1.The shipment by air, sea or express(DHL/FEDEX/TNT/UPS/EMS/City-line).
2.The packaging is standard export wooden case&carton case or as your requirement.
General Features
• The laminated piston ring offers important advantages such as unbeatable efficiency and thermal shock resistance
• High allowable speeds and operating pressures means high output power
• The unique piston locking, timing gear and bearing set-up as well as the limited number of parts add up to a very robust design with long service life and, above all, proven reliability.
Domestically Produced Fan Pumps and Fan Motors: Comprehensive Overview
1. Introduction
Domestically produced fan pumps and fan motors are critical components in various industrial machinery, construction equipment, and cooling systems. These components are designed to regulate airflow and maintain optimal operating temperatures, ensuring the efficiency and longevity of the machinery they serve.
2. Key Features
• High Efficiency: Modern domestically produced fan pumps and motors are engineered for high energy efficiency, reducing operational costs and environmental impact.
• Durable Construction: Built with robust materials, these components withstand harsh working conditions, including extreme temperatures and vibrations.
• Customizable Specifications: Manufacturers offer a range of sizes, power ratings, and flow rates to suit diverse application requirements.
• Advanced Control Systems: Integrated with smart sensors and controllers, these components allow for precise regulation of fan speed and airflow.
3. Applications
• Construction Equipment: Used in excavators, loaders, and cranes to cool hydraulic systems and engines.
• Example: In SANY excavators (models 375, 485, 550, 650, 750), domestically produced fan pumps and motors ensure optimal cooling performance.
• Industrial Machinery: Employed in manufacturing plants to maintain temperature stability in machinery and production lines.
• HVAC Systems: Critical for air conditioning and ventilation systems in commercial and residential buildings.
• Automotive Industry: Used in engine cooling systems and auxiliary climate control units.
4. Technical Specifications
• Flow Rate: Ranges from a few liters per minute (LPM) to several hundred LPM, depending on the application.
• Pressure Rating: Typically operates within a pressure range of 10-30 bar, with higher-pressure models available for specialized applications.
• Power Consumption: Varies based on size and efficiency, with energy-efficient models consuming significantly less power.
• Noise Level: Modern designs incorporate noise-reduction features, operating at levels below 70 decibels (dB) in most cases.
5. Advantages of Domestically Produced Components
• Cost-Effectiveness: Lower production costs compared to imported alternatives, resulting in more competitive pricing.
• Quick Delivery: Shorter lead times due to local manufacturing and supply chain efficiency.
• After-Sales Support: Easier access to technical support, spare parts, and warranty services.
• Customization: Greater flexibility in adapting products to meet specific customer requirements.
6. Comparison with Imported Products
【表格】
Aspect Domestically Produced Imported
Cost Lower Higher
Lead Time Shorter Longer
Customization Higher Flexibility Limited
Warranty Local Support May Vary
Quality Comparable to Imports High
7. Case Study: SANY Excavators
SANY, a leading manufacturer of construction equipment, utilizes domestically produced fan pumps and motors in its excavator models (375, 485, 550, 650, 750). These components are integral to the machinery's cooling system, ensuring reliable performance even under demanding conditions.
• Model 375: Compact design with a fan pump rated at 50 LPM and a motor power of 5 kW.
• Model 485: Enhanced cooling capabilities with a 75 LPM fan pump and a 7.5 kW motor.
• Model 550: Heavy-duty application with a 100 LPM fan pump and a 10 kW motor.
• Model 650: High-performance cooling with a 125 LPM fan pump and a 12.5 kW motor.
• Model 750: Industrial-grade cooling with a 150 LPM fan pump and a 15 kW motor.
• The 40° angle between shaft and cylinder barrel allows for a very compact, lightweight motor/ pump.
• Small envelop size and a high power-to-weight ratio
• The motor version has highly engineered valve plates for high speed and low noise
• The pump version has highly engineered valve plates for increased self priming speed and low noise, available with left and right hand rotation.
• The F11's and F12's have a simple and straight-forward design with very few moving parts,making them very reliable motors/pumps.
• Our unique timing gear design synchronizes shaft and cylinder barrel, making the F11/F12 very tolerant to high 'G' forces and torsional vibrations.
• Heavy duty roller bearings permit substantial external axial and radial shaft loads.
