The function of the red grooved 45-degree elbow is to deflect the direction of the pipe by 45 degrees in grooved fire fighting pipes systems, enabling flexible pipe layout, facilitating pipe bending and connection, ensuring smooth fluid transition at bends, and improving installation efficiency and system performance. Silver Galvanized fittings and red Grooved fittings are used, with red typically indicating use in fire protection systems for easy identification.
Main Functions:
Direction Change: Connects two pipe sections at a 45-degree angle, allowing the pipeline to change direction in space.
Increased Flexibility: Allows for more flexible pipe system layout in complex environments (such as ceilings and walls), adapting to different building structures.
Maintained Flow: Well-designed elbows reduce fluid resistance, ensuring stable water flow or media flow.
Fast Installation: Using grooved connections and clamp connections, it is faster and more economical than traditional welding and threaded connections.
| Nominal diameter | Basic dimensions | |
| D | L | |
| 50 | 60 | 45 |
| 65 | 76 | 51 |
| 80 | 89 | 53 |
| 100 | 108 | 58 |
| 125 | 133 | 63.5 |
| 150 | 159 | 68.5 |
| 200 | 219 | 90 |
| 250 | 273 | 103 |
