The main products named Jinan Jichai include diesel engines,diesel gensets,gas engine and gas gensets.Jinan Diesel Engine CO.Ltd(JDEC) has begun to develop Series 190 Marine diesel engines since the beginning of 1980s which have been enlarged for several hundred models,such as 16V,12V,8V,6L,4L,ect.The power range is from 160 to 2400KW while the speed are 1000rmp,1200rmp,1300rmp,1450rmp and 1500rmp separately.These engines are widely applied for all kinds of vessels and power take off equipments,such as,naval vessels,fishers,dredgers,passenger liner,freight liner,oil vessels,engineering vessels,ect,which are sold to many areas and countries of Southeast of Asia,South American or North Africa.
Product Description
1000 kw diesel generator & 1250kva generators for Nigeria from China quality manufacturer, suits for oil field, industrial and residential power generation plant.
Model No.
1000GF-C
Rated power
1000KW /1250KVA
Standby power
1100KW/1375KVA
Output voltage
230/400V
Rated speed (r/min.)
1500
Noise level
70-75 dB ( silent type ) / 90-110 db ( open type)
Power factor
COSΦ=0.8（lagging）
Phase/wires
3 phase 4 wires
Start mode
Electric
Fuel consumption
205g/kw.h @ 100% loaded
Rated currency
1800amps
Detailes Photo
Our Product
190 Series Parts
| Spare parts for 12V190 | |||
| No. | Part Name | Part Number | Qty |
| 1 | CYLINDER BLOCK ASSEMBLY | 1 | |
| 1 | |||
| 3 | CYLINDER HEAD ASSEMBLY | 127.03.00 | 12 |
| 4 | OIL SUMP ASSEMBLY | 12VB.04.00B | 1 |
| 5 | PISTON AND CONNECTING ROD ASSEMBLY | 127.05.00 | 12 |
| 6 | CAMSHAFT AND GEAR TRAIN ASSEMBLY | 127.06.00 | 1 |
| 7 | TORSIONAL VIBRATION DAMPER ASSEMBLY | 12VB.07.00 | 1 |
| 8 | INTAKE LINE ASSEMBLY | 127.08.00B | 1 |
| 9 | EXHAUST LINE ASSEMBLY | 127.09.00A | 1 |
| 11 | NATURAL GAS PIPELINE | 127.14.00 | 1 |
| 12 | MEGNETO TRANSMISSION ASSEMBLY | 127.15.00 | 1 |
| 13 | OIL PUMP ASSEMBLY | 12V.17.00C | 1 |
| 14 | OIL FILTER ASSEMBLY | 12VB.18.00B | 1 |
| 15 | CENTRIFUGAL FILTER ASSEMBLY | 12VB.19.00 | 1 |
| 16 | LUBRICATING PIPING | 127.20.00 | 1 |
| 17 | OIL COOLER ASSEMBLY | 12VB.21.00 | 1 |
| 18 | WATER PUMP ASSEMBLY | 12VB.22.00B | 2 |
| 19 | Cooling line system | 127.24.00 | 1 |
| 20 | INTER-COOLER ASSEMBLY | 12V.27.00 | 1 |
| 21 | HAND PRIMING OIL PUMP ASSEMBLY | 12V.29.00 | 1 |
| 25 | OVERSPEED SAFETY DEVICE | 12VB.37J2.00 | 1 |
| 26 | SPECIAL TOOLS | 127.42.00 | 3 |
| 27 | COUPLING ASSEMBLY | 163.44.00 | 1 |
| 29 | ELECTRIC STARTING SYSTEM | 127.46D.00 | 1 |
| 30 | OIL PUMP BRACKET ASSEMBLY | 12VB.48.00 | 1 |
| 31 | CARBURETTER ASSEMBLY | 127.86.00 | 2 |
| 32 | NATURAL GAS PRESSURE REGALATING VALVE | 127.87.00 | 1 |
| 33 | GOVERNOR CONNECTION ASSEMBLY | 127.89.00 | 1 |
| 35 | Electromagnetic valve | 127.91.00 | 1 |
| 36 | TURBOCHARGER ASSEMBLY | 127.20GJ.00EB | 2 |
Our project is a waste reprocessing power generation, energy saving and emission reduction, but also can create benefits.
