J-Tron focuses on the design and production of Micro Gear Pump, Mini Solenoid Valve, and Liquid Control Component. Just share your technical specifications, operating conditions, and assembly dimensions with us. Our expert team will then craft customized solutions and product designs that align perfectly with your requirements.

PRODUCT DISCRIPTION: Gear Pump for Continuous Ink Jet Printer

J-Tron's Gear Pump for Continuous Ink Jet Printer--GPT Series is applicable to inkjet printing, pigment printing, ceramic spraying, chemcial metering system, and wide range of aggressive chemicals media and abrasive fluids.

This GPT Series precision pump has flow rate at 3.5L/min at 5400RPM, displacement is 0.63ml/Rev, and max differential pressure at 8Bar. The revolution range among 500~5500RPM and the viscosity range among 0.5~1500cps. It has outstanding self-priming capacity that the suction lift is 2 meters, and it has a max head of 80meters.

This GPT Series precision pump is made of Titanium Nitride coated stainless steel 316 pump body, tungsten carbide PEEK, ceramic shaft, and rare earth magnets that ensures the wear resistance and corrosion resisrtance.

This GPT Series precision pump features a cavity style design with no dynamic seals for applications that cannot tolerate leak.

Please feel free to contact us for more information.

SPECIFICATION: Gear Pump for Continuous Ink Jet Printer

Technical Parameter
Portfolio	GPT3500
Flow Rate	3.5L at 5500RPM
Displacement	0.63ml/Rev
Sunction	2Meters
Max Differential Pressure	8Bar
Revolution Range	500~5500RPM
Viscosity Range	0.5~1500cps
Connection	NPT1/8
Material
Pump Body	TiN Coated SS316
Gear	Tungsten Carbide
Shaft	Ceramic
Magnets	Rare Earth
Brushless Motor
Voltage	24V DC
Drive Control	0~5V DC & PWM 0-100%
Power Consumption	70W
