2021 XCMG Brand Used 30 Ton Crane Mobile Cranes XCT30_Y Chinese Truck Cranes for Sale
XCT30_M Truck crane is widely used for the lifting operations in Oilfields, mines, general engineering projects, such as construction site, urban renewal, communication and transportation, ports, bridge, oilfields and mine, and complex working environments.
5-section boom of 40.5m with U-type profile is adopted; the max. lifting load is 30t; the max. lifting height is 48.1m; the max. working radius is 38.4m; The performance takes the lead comprehensively.
Various configurations for working conditions in oilfields and municipal constructions can meet the all the requirements.
The entire machine is designed to endure high temperature, it is allowed to work in ambient temperature up to 60ºC. With dust-proof parts equipped, the crane is applicable to applications in deserts.
| Item | Unit | Parameter |
|---|---|---|
| Dimensions (length x width x height) | mm | 12362×2550×3415 |
| Total vehicle mass in travel configuration | kg | 30000 |
| Axle load | 1st and 2nd axle: 6400 kg | |
| 3rd axle: 11800 kg | ||
| Engine rated power | kW/(r/min) | 192/2200 |
| Max. output torque | N.m/(r/min) | 1000/1400 |
| Max. travel speed | km/h | 85 |
| Min. turning diameter | m | 20 |
| Min. ground clearance | mm | 261 |
| Approach angle | ° | 16.5 |
| Departure angle | ° | 13 |
| Max. grade ability | % | 40 |
| Fuel consumption per 100 km | L | 32 |
| Max. total rated lifting capacity | t | 30 |
| Min rated working radius | m | 3 |
| Max. load moment | kN.m | Base boom: 965 |
| Fully-extended boom: 576 | ||
| Outrigger span | Longitudinal: 5.23 m | |
| Lateral: 6.4 m | ||
| Hoist height | m | Base boom: 10.5 |
| Fully-extended boom: 40.3 | ||
| Boom length | m | Base boom: 10.4 |
| Fully-extended boom: 40.5 | ||
| Jib offset angle | ° | 0,15, 30 |
| Boom raising time | s | ≤38 |
| Boom fully extending time | s | ≤90 |
