JANBO Auto Slitting & Rewinding Machine for Various Paper and Film Materials

This machine is suitable for slitting and rewinding of various Jumbo roll materials, such as Label paper ,release paper, glassine paper, crepe paper, laminated paper, carbonless paper, white card paper, cigarette packaging paper, kraft paper, non-woven fabric, aluminum foil, self-adhesive materials, PVC plastic, release film and other log rolls.

1. 3 motors synchronous drive control system, ensuring high speed operation with stable tension control and aesthetically pleasing finished products.

2. Siemens PLC programmable logic controller central system; LED touchscreen interface for tension, slitting length/width, and parameter input.

3. Shaftless independent moveable unwinding base (Optional configurations: shaft/shaftless integrated or shaft/shaftless separate type).

4. 3" & 6" unidirectional torque chuck with conical chuck; Electric bilateral chuck actuation; Hydraulic lifting arms loading; Separable paper splice table.

5. Closed-loop tension control system integrated with ultrasonic automatic edge-guiding system.

6. Rewind pressure roller assembly with adjustable pneumatic pressure, suitable for various material slitting/rewinding requirements.

7. Quick-change rewind shaft system (air shaft ↔ differental shaft interchangeable).

8. Ultrasonic signal detection coupled with electronic full-automatic torque controller.

9. Ultrasonic detection synchronized with PLC algorithm and host line speed comparison control.

10. 2 PCS high-frequency electrostatic eliminator bars for effective static removal during rewinding.

11. The waste treatment device adopts a fan waste collection.

12. Optional tooling configurations: Pneumatic circular knives, upper/lower circular blade, industrial straight knives (fulfilling diverse material processing needs).

13. Lower knife with automatic positioning (knife gap setting) for precise alignment and enhanced efficiency.

14. Servo-driven ball screw automatic pusher with paper core positioning, reducing operator workload.

15. Independent rotating finished roll unloading device (equipped with air shaft and packaging).

Parameter	Specification
‌Machine Width‌	1.0M / 1.3M / 1.6M /1.8M / 2.0M
‌Min. Slitting Width‌	25 mm
‌Max. Unwinding Diam.‌	1200 mm
‌Max. Rewinding Diam.‌	800 mm (dual shafts upper/lower)
‌Max. Mechanical Speed‌	300 m/min
‌Core Inner Diameter‌	3" or 6"
‌Power Supply‌	380V / 3PH / 50Hz
‌Air Supply‌	0.6 MPa

Description: The JANBO Auto Slitting & Rewinding Machine is a versatile converter equipment designed for cutting and rewinding a wide range of materials including label paper, release paper, kraft paper, thermal paper, aluminum foil, and more. It is also suitable for handling double shafts semi-automatic cutting & rewinding of kraft mirror paper, coated paper, and other backing materials. This machine is ideal for converting jumbo rolls into smaller rolls with precision and efficiency.

Detailed Description: The Cutter Slitter Rewinder Converter Equipment by JANBO is a reliable and high-performance machine that ensures accurate cutting and rewinding of different materials. It is designed to meet the demands of various industries such as printing, packaging, and labeling. With its double shafts and semi-automatic operation, this machine offers efficiency and precision in converting jumbo rolls into smaller rolls for further processing.
