Product details

Polyester Insulation Tubes

Product Overview

Crafted from DuPont MO material, these polyester insulation tubes deliver exceptional environmental performance. They are free of harmful substances and fully compliant with eco-friendly standards, making them suitable for a wide range of industrial and commercial applications.

Technical Parameters

VarietyCapability	Polyester	Low Shrinkable Poly ester	Heat Shrinkable Poly ester
shrinkable rate(radical)	<2%	8-12%	32%
shrinkable rate(portrait)	<2%	8-12%	35%

working temperature	-60℃-150℃
melting temperature	250℃-255℃
voltage to strike thro ugh	25℃(50cycle)) 2650v.0.0254mm/min 125℃(50cycle) 2125V,0.0254mm/min
flammability	spontaneous quench
resistance	The conductor is resistant to acid and alkali corrosion,impregnation, mildew, corona discharge,industrial solvent, external mechanical damage, oil and special liquid
sopping capacity	Maximum absorption is 75% after 24 hours immersion
toluene extraction	<2%

Dimensional Specifications

Inner Diameter (ID): Ranges from 0.026 inch to 2 inches (with a metric equivalent of 0.66mm to 50.8mm)
Length: Available in sizes between 0.62 inch and 48 inches (corresponding to 57mm and 1219mm)
Wall Thickness: Varies from 0.001 inch to 0.03 inch (converting to 0.0254mm to 0.76mm)
Color Options: Transparent, solid colors, and striped patterns

Application Fields

These polyester insulation tubes are primarily designed for temperature-resistant insulation and mechanical protection of diverse components, including but not limited to:

Solder joints, electrical connectors, coils, transformers, and electric motors
Wires, heating elements, capacitors, and telephone relays
Thermostats, electronic devices, and wire harnesses for household appliances
Automotive wire harnesses, power cables, and metal pipelines

Customization Guidelines

For tubes with an inner diameter less than 1.0 inch: A specialized production process is required, and the wall thickness is fixed at 0.03 inch (thickness customization is not available).
For tubes with an inner diameter of 1.0 inch or larger: Wall thickness can be tailored to specific requirements:

1.Inner diameter 1.2–2.0 inches: Wall thickness options span from 0.05 inch to 0.1 inch

2.Inner diameter ≥ 2.0 inches: Wall thickness can be adjusted between 0.025 inch and 0.05 inch
