Type TS Tubing Spiders

2 week ago

3 0

Ryanster Petroleum Equipment Co,.Ltd

 5 month year

Product details

TS-100 tubing /casing spiders are tools for handling drill collars, casings, tubings and slick pipes. Both the spider body and slips are made of high-quality alloy steel and heat-treated especially. The spiders are not so weighty and easy to operate. They are designed and manufactured according to API Spec 7K specification for drilling and well servicing equipment.

The API spider same API Split master bushing with a diameter of 4in/ft on the diameter taper. The spider is made of high -quality alloy steel and heat-treated especially. The Spider are easy to operate.

Features

TS tubing spider Interchangeable slip body inside the spider
API spider is made of alloy steel according to API standard
NDT test with national best standard
Quality assured, warranty 6month after sale, spare parts are traceable to provide

In addition, we also offer various models of Spider, including type QQP, C, SE, etc. We also offer high-quality products such as Tong, Slip, Clamp and Elevator, etc.

Apart from the Pneumatic Spider, there are many other important pieces of equipment in the field of oil drilling that work together to complete complex tasks.

1. **Top Drive (Top Drive System)**: A new generation of power transmission system for drilling that replaces the traditional rotary table drive method. It is directly connected to the top of the drill string, providing rotational torque and axial load, supporting continuous drilling, and significantly enhancing drilling speed and flexibility.

2. **Mud Pump**: One of the core components of the mud circulation system, it is responsible for pumping drilling fluid from the surface to the bottom of the well and shooting it out at high speed through the drill bit nozzles to cool the drill bit, carry cuttings back to the surface, and maintain the stability of the wellbore.

3. **Solids Control System**: This is an integrated processing unit composed of multiple separation devices such as vibrating screens, desanders, and desilters, aiming to effectively remove solid particle impurities from the drilling fluid, ensuring the stability of the drilling fluid performance, reducing wear on the drill string, and extending the drilling cycle.

These devices work in coordination to form a complete technical support system for oil drilling, which plays an irreplaceable role in ensuring safe production and improving work efficiency.
