Engineered for precision and long-term reliability, this board to board connector is designed to provide stable and efficient electrical connections between two printed circuit boards. With its compact form and durable construction, it ensures both mechanical stability and consistent conductivity, making it an essential solution for modern electronic systems where space and performance are equally critical.
One of the key strengths of this connector lies in its adaptability. It supports a wide range of applications thanks to its poles ranging from 2 to 16P, making it suitable for designs that require both low- and mid-level circuit density. The pcb board connector is manufactured with high-quality Nylon66 housing that meets UL 94 V-0 standards, ensuring flame retardancy and safety under demanding operating conditions. The contacts are engineered to achieve a resistance of ≤ 20mΩ, ensuring efficient signal transmission with minimal energy loss.
In terms of performance, the connector is rated for 2.0A AC/DC current and can operate at up to 250V AC/DC, which provides sufficient capacity for most electronic applications. It withstands up to 800V AC per minute, further enhancing reliability in harsh conditions. The temperature operating range from -25℃ to +85℃ enables it to work across a wide array of environments, from industrial control systems to consumer electronics. The insulation resistance of ≥ 1000MΩ ensures strong protection against leakage currents, while the design supports wire sizes from AWG #30 to #24. Additionally, the connector is compatible with PCB thicknesses of 1.2mm, aligning well with common board design standards.
The electronic board connector finds wide usage in devices such as industrial automation controllers, communication equipment, consumer electronics, automotive electronics, and more. Its stable mechanical design reduces assembly errors and ensures easy installation and maintenance. The flame-retardant housing and reliable contact system make it an excellent choice for engineers looking for long-lasting solutions in compact electronic designs.
Q: What is the current rating of this connector?
A: It is rated at 2.0A AC/DC.
Q: Can it handle temperature fluctuations in industrial environments?
A: Yes, it works reliably between -25℃ and +85℃.
Q: Which PCB thickness is it compatible with?
A: It is designed for PCB boards with 1.2mm thickness.
Q: Is the housing material flame-retardant?
A: Yes, it is made of Nylon66 UL 94 V-0.
