Features:
l With fully hydraulic design, this machine features high pressure and, therefore, firm jointing.
l Sole and edge attaching and front and rear tightening can be undertaken in one operation or independently. Hence, it is suitable for flat, walled or specially walled type shoes. It can be used for three purposes and is cost effective indeed.
l The use of multiple edge pressing hydraulic cylinders ensures uniform and overall pressing. The primary and secondary pressing plus pressing after forming will eliminate the incomplete pressing points and make the sole attaching flawless.
l The strut mechanism adopts automatic hydraulic balancing system. The height of strut is not necessary to make adjustment, making the operation simple and easy.
l The automatic swing angle positioning design of the strut mechanism makes it easy to remove shoes, especially in operation with boots of half boots.
l When the mechanism of front and rear tightening backs up, the special circuit design can control its backward range, making it easy to change shoes of different size.
l The "floating sole adhesive film structure", composed of many mini cylinders on the bottom of the pressing base, can make the pressing of irregular soles with radian compliant.
|
Dimension |
1220*1280*2040mm |
|
Power |
3kW |
|
Voltage |
380V/50Hz |
|
Net weight |
1250KG |
|
Gross weight |
1300KG |
