Features:
l Forming station are ergonomic design. Patented products, counterfeiting must be investigated.
l Equipped with PLC and touchscreen system for easier operation.
l Suitable for regular toe forming or stitch-down forming.
l Suitable for forming of toe made by different materials.
l Top and bottom hot molds can heat and soften the upper simultaneously to ensure a perfect softening result.
l The use of ptfe and pincers in cold molds allows machine to work on uppers with different thickness while keep a perfecting forming result.
l Molds can be customized according to customer's lasts for better forming precision.
l Hot stations are equipped with a steaming system that makes the upper more flexible and lustrous.
l Equipped with environment-friendly and high-speed cooling system with extreme cooling temperature of up to -20℃.
l After forming, the lining, glue sheet and upper are closely jointed without wrinkle, distortion, nor bubble.
Safety protection:
l Equipped with low voltage footswitch for positioning.
l Equipped with firefighting-class over-temperature protection that reacts in 0.1s under abnormal heating situation.
l Equipped with LED work indicator in 3 colors.
l Comes with operator and administrator system for quality control.
|
Dimension |
900*1390*1870mm |
|
Power |
2.7kW |
|
Voltage |
220V/50Hz |
|
Net weight |
380KG |
|
Gross weight |
450KG |
If you are interested in the product, contact 2bvideo.com for more information for more information
