Wave shale shaker screen

9 month ago

22 0

Ryanster Petroleum Equipment Co,.Ltd

 2 year year

Product details

The petroleum vibrating screen is a crucial solid control equipment used in petroleum drilling to separate drilling fluid from drill cuttings. Its core function lies in enhancing the cleanliness of the drilling fluid through vibrating screening, thereby ensuring the drilling efficiency and safety. During the petroleum extraction process, just like the mud pump, the control of solid phases in the drilling fluid is of vital importance to the drilling efficiency and the lifespan of the equipment. The petroleum vibrating screen mesh, as the first checkpoint of the solid control system, its performance directly determines the purification effect of the mud and the drilling cost. Together with the pressure control equipment and the drill string, it ensures the safety and efficiency of the drilling process.

Wave shale shaker screen(Corrugated screen) is named by his special corrugated form.Main feature as follows:
These products screen panels are constructed with two or three 304 or 316 stainless steel wire cloth layers, after compounded and bended, with a steel backing plate combined together. The wire cloth and bottom steel backing plate combined tightly, increase the filtering area 120% to 150% more than hookstrip flat screen, get an better effective.

Different layers with different density.To arrange these layers reasonably and exactly, the screening effect will become more and better. Screen with different mesh counts with suitable opening sizes of the backing plate. Doing so, our products will obtain the largest effective area under the condition of enough strength.

The bottom layer with low mesh counts has coarse wire and can be tight bonded to the backing to make up one block. So the strength of whole screen mesh get up and the useful life is increased.

Advantages

Increased Shaker Capacity.
Makes Fine Separations.
Fits Existing Shakers.
Screen Finer Faster.
Drier Cuttings.

Specification

Material: SS304/SS316L
Body Material: Stainless steel plate
Construction Type: Wave Type
Package: 2 pcs per carton, packed in per wooden case.
