High Speed Paper Taping Machine: Efficient and Reliable Solution for Fast Paper Taping Apparatus

1. Equipment Overview

The High Speed Paper Taping Machine is an advanced device designed to streamline the process of sealing and taping paper products with remarkable speed and precision. As a Fast Paper Taping Apparatus, it is ideal for industries requiring consistent, high-quality sealing of paper-based materials—including packaging, shipping, and manufacturing. This High Speed Paper Sealing Equipment ensures quick, efficient application, reducing labor costs and boosting productivity.

2. Production Range

1) Bare wire parameter Conductor width: 3.5～25mm

Conductor Thickness: 1～8mm

Single wire section ：10~150.0mm²

Yield strength: 60 ~200N/mm²

2) Insulation material: Cable paper, film and Nomex paper are suitable. Insulation thickness: 0.04mm-0.125mm , band width: 10～32mm.

3) Insulation layers: 4 layers, max 16 layers at one time.

4) Pitch range of taping head: 10～32.

5) Pad diameter: 330 mm(max)

6) Pad core diameter: 75mm

7) Maximum speed of taping head: 800RPM/min

8) Line speed: 0—16M/min

9) Power supply: 380V 60Hz
