Solenoid Valve with Flat Tab

10 month ago

14 0

J-Tron Technologies Zhuhai Co., Ltd

 2 year year

Product details

Product Description

J-Tron 24V DC solenoid valve is the high performance thermal resistant solenoid valve for both liquid and gas control and transfer. This miniature solenoid valve is direct-acting type with 2/2 way and normally closed. 1.3mm for the orifice diameter. POM for the valve body. FFKM for the bobbin gasket. EPDM for the valve bushing seal gasket. -0.8bar to 4bar for the operating pressure range. 30ms for the response time. 0 Deg C to 60 Deg C for both media temperature range and ambient temperature range. Inlet 7bar and outlet 6bar for the leak rate. More than 7,000,000 cycles by lifetime. 24V DC voltage. 150 ohm. 3.8W power consumption. 1000VAC insulation. Flat tabs coil connections way.

Advantage

J-Tron FFKM solenoid valve is compact designed that can save space. Its fast response time can help equipment control liquid and gas accurately.

Application

J-Tron 2-way micro solenoid valve is the compact solenoid valve for harsh environment such as it can use in the inkjet printer that can control and transfer ink with particulate matters. J-Tron miniature solenoid valve with fast response time is good alternative for IMI Norgren.

Contact Now

If you are interested in the product, contact 2bvideo.com for more information for more information

To:: J-Tron Technologies Zhuhai Co., Ltd

Message:

Submit

Disclaimer：

The information of 2bvideo.com limited shown above is provided by the user or collected on the network. Video 2B does not guarantee the authenticity,accuracy and legitimacy of 2bvideo.com limited information. Video 2B does not involve legal relationships and disputes between users arising from transactions other than secured transactions on this website. Disputes shall be settled by you through negotiation. If you are the person in charge or relevant employee of this enterprise, if you find that the enterprise information is incorrect or want to manage thiscompany, please contact us jacklee1558@gmail.com, after you claim the enterprise, you can obtain management permission, publish supplyand demand information, bring consulting orders, and remove page advertisements.

J-Tron Technologies Zhuhai Co., Ltd

 Audited supplier

2 year

Address: Zhuhai, China

Main Product: Micro Gear Pump , Miniature Diaphragm Vacuum Pump, Mini Solenoid Valve, Media Separated Solenoid Valve, Liquid Control Component, Customized Gear Pump
