1. Product Overview

This wire harness features a white flat parallel twin-core cable with visible pink/red printed stripe markings for polarity identification, terminated on both ends with white JST-compatible small-pitch connector housings. The flat parallel cable construction keeps the two conductors side by side in a neat, compact form that routes cleanly through tight spaces and lies flat against PCBs or enclosure walls without bulking up the interior.

The printed stripe on the cable body serves as a clear polarity marker — one conductor carries the stripe, the other is plain white — eliminating polarity confusion during assembly and rework without requiring color-coded wires. This design is particularly valued in applications where clean aesthetics and assembly efficiency are both priorities.

The connector housings visible in the image are consistent with JST PH (2.0 mm pitch) or ZH (1.5 mm pitch) series, commonly used for low-current signal and power connections on compact PCBs. Each harness is produced with automated crimping and undergoes 100% continuity testing before shipment. Custom length, pitch, pin count, wire gauge, and cable type are available on request.

Key features:

Flat parallel twin-core cable for neat, compact routing

Printed stripe polarity marking — no color-coding confusion

JST-compatible white housing with gold/tin-plated crimp terminals

Automated machine crimping for consistent terminal quality

100% continuity tested before shipment

RoHS compliant materials

OEM/ODM accepted, small orders and prototype quantities welcome

2. Technical Specifications

Parameter	Specification
Connector Style	JST PH / ZH series compatible (2.0 mm or 1.5 mm pitch)
Pin Count	2P (custom multi-pin available)
Wire Type	Flat parallel twin-core, white jacket with printed stripe
Wire Ggeau	AWG 26 / 28 / 30 (custom on request)
Conductor	Stranded copper
Polarity Marking	Printed pink/red stripe on one conductor
Cable Length	Custom length; please specify at inquiry
Rated Voltage	Up to 100V DC (series dependent)
Rated Current	Up to 1 A per contact (AWG 28 standard)

3. Application Scenarios

Consumer Electronics & Wearables The flat parallel cable format is widely used inside slim consumer devices such as fitness trackers, wireless earbuds, portable chargers, and compact cameras where minimizing internal cable volume and maintaining a clean build are both important.

PCB-to-PCB Internal Signal Connections Ideal for connecting small PCBs inside smart home sensors, IoT modules, and wireless communication devices where board-to-board signal lines must route neatly through narrow slots or along flat surface channels.

Battery Pack & Charging Modules Used as the balance or signal lead between compact lithium cell packs and BMS boards in small battery modules, where the 2-pin format covers cell voltage monitoring or charging status lines.

3D Printers & Maker Electronics Popular in end-stop switches, filament runout sensors, and auxiliary sensor connections where a thin, flat cable reduces interference with moving parts and keeps the build tidy.

Medical & Portable Diagnostic Equipment The flat cable profile and clear polarity marking make this harness suitable for internal signal connections inside handheld diagnostic devices and portable health monitors where compact assembly and error-free wiring both matter.

LED Lighting Control Boards Used to connect control dimming signals or thermal sensor feedback lines between driver boards and controller PCBs inside LED luminaires and display panels.

4. FAQ

Q: Are you a trading company or a manufacturer/factory?

A: We are a factory.

Q: How do you guarantee product quality?

A: Quality is our lifeline. All raw materials we use are non-toxic and environmentally friendly, and we have a professional QA/QC team to ensure quality.

Q: Do you provide samples? Are they free or extra?

A: We provide free samples; you only need to pay for shipping.

Q: What is your delivery time?

A: Samples usually take 5-7 days, while mass production takes 10-15 working days, depending on the quantity.

Q: What is your minimum order quantity?

A: One piece is also our minimum order quantity.

Q: Do you accept OEM or ODM orders?

A: Yes, we accept OEM and ODM orders from our customers.
