Product details

PVC-M water supply pipe is a new generation of pvc high impact pvc pipe, pvc pipe to maintain high strength characteristics on the basis of enhanced material ductility and cracking, with good toughness and high resistance Pressure capacity, is the ideal water supply pipe network products.

PVC-M pipe with high impact, high toughness, low cost, easy construction features, suitable for a variety of complex and changeable construction environment, its excellent quality to ensure the flexibility of construction, stability, compared with ordinary pvc pipe A revolutionary breakthrough, combined with the pvc rigid and pe toughness, while the pressure than the national standard to improve a level. The use of non-polar rigid particles and elastic toughening, enhance the pvc material, breaking the use of elastomer toughened pvc pipe to bring the hydrostatic strength of the problem, integrated material modification, processing technology and other means, has been affected pvc pipe quality Of the factors that can better guarantee the quality of products. The project has a wide range of applications, but also can be applied to agricultural irrigation, chemical pipelines and other materials on the impact of high performance requirements.

There are two types of PVC pipes for water supply:one is connected by solvent cement,and the other by rubber ring.

Outside Diameter(mm)	0.63MPa	0.8MPa	1.0MPa	1.25MPa	1.6MPa
Outside Diameter(mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	壁厚 (mm)
63			2.0	2.5	3.0
75		2.0	2.3	2.9	3.6
90	2.0	2.2	2.8	3.5	4.3
110	2.2	2.7	3.4	4.2	5.3
125	2.5	3.1	3.9	4.8	6.0
140	2.8	3.5	4.3	5.4	6.7
160	3.2	4.0	4.9	6.2	7.7
180	3.6	4.4	5.5	6.9	8.6
200	3.9	4.9	6.2	7.7	9.6
225	4.4	5.5	6.9	8.6	10.8
250	4.9	6.2	7.7	9.6	11.9
280	5.5	6.9	8.6	10.7	13.4
315	6.2	7.7	9.7	12.1	15.0
355	7.0	8.7	10.9	13.6	16.9
400	7.9	9.8	12.3	15.3	19.1
450	8.8	11.0	13.8	17.2	21.5
500	9.8	12.3	15.3	19.1	23.9
630	12.3	15.4	19.3	24.1	30.0
710	13.9	17.4	21.8	27.2	33.9

Outside Diameter(mm)	0.63MPa	0.8MPa	1.0MPa	1.25MPa	1.6MPa
Outside Diameter(mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	壁厚 (mm)
20					2.0
25					2.0
32					2.0
40					2.0
50				2.0	2.4
63			2.0	2.5	3.0
75		2.0	2.3	2.9	3.6
90	2.0	2.2	2.8	3.5	4.3
110	2.2	2.7	3.4	4.2	5.3
125	2.5	3.1	3.9	4.8	6.0
140	2.8	3.5	4.3	5.4	6.7
160	3.2	4.0	4.9	6.2	7.7
180	3.6	4.4	5.5	6.9	8.6
200	3.9	4.9	6.2	7.7	9.6
225	4.4	5.5	6.9	8.6	10.8
250	4.9	6.2	7.7	9.6	11.9
280	5.5	6.9	8.6	10.7	13.4
315	6.2	7.7	9.7	12.1	15.0
355	7.0	8.7	10.9	13.6	16.9
400	7.9	9.8	12.3	15.3	19.1

Specification/Models

Full 20mm through 710mm availability

Product Feature

1) Light weight, nice figure.

2) Acidproof, alkaliproof, pressureproof.

3) Easy to load and unload.

4) High flow capacity, endurable, nontoxic.

5) Good resistance to water pressure and good electric insulation.
