This is C113968968 C140745 C140746 diaphragm repair kit for ASCO type pulse valve SCR353A230, SCR353G230, SCXR353A230, SCXR353G230. The NBR diaphragms durable and suitable for general chemicals, such as oil, water, fuel, etc. One set contains 2 diaphragms and a spring, packaged in plastic bag. Different valves match different diaphragms. We have other ASCO type pulse valve diaphragm to choose from, C113685, C113825, C113827, C113928, etc. And we also produce pulse valve solenoid coils, pulse valve solenoid armature and pulse jet valves.
|
Pulse Valve
Port Size
|
Pulse Valve
Model No
|
Diaphragm
Model No
|
Diaphragm Material
|
|
3/4''
|
SCG353A043 SCG353G043 SGG353A043
|
C113444
|
TPE, NBR
|
|
1''
|
SCG353A044
SCG353G044
SGG353A044
|
||
|
3/4''
|
SCG353-052
SCG353G052
SGG353-052
|
||
|
1''
|
SCG353-053
SCG353G053
SGG353-053
|
||
|
1 1/2''
|
SCG353A047
SCG353G047
SGG353A047
|
C113827
|
NBR
|
|
SCG353A065
SCG353G065
SGG353A065
|
|||
|
2''
|
SCG353A050
SCG353G050
SGG353A050
|
C113685, C113686
|
|
|
2 1/2''
|
SCG353A051
SCG353G051
SGG353A051
|
||
|
3''
|
SCG353D060
SCG353G060
|
C123432, C123433
|
|
|
3''
|
SCXE353.060
SCR353G060
|
C113928
|
|
|
3''
|
SCR353A230
SCR353G230
|
C113968968, C140746
|
|
|
3 1/2''
|
SCR353A235
SCR353G235
|
C113968968, C140745
|
|
|
3/4''
|
G353A041
|
C113443
|
TPE, NBR
|
|
1''
|
G353A042
|
||
|
3/4''
|
G353-055
|
||
|
1''
|
G353-056
|
||
|
1 1/2''
|
G353A045
|
C113825
|
NBR
|
|
G353-066
|
|||
|
G353A046
|
C113826
|
||
|
G353A063
|
|||
|
2''
|
G353A048
|
C113684
|
|
|
2 1/2''
|
G353A049
|
NBR Material Diaphragm
The material of C113968968 big diaphragm is NBR, which has good thermal aging resistance and can withstand operating temperatures from -10 to 80℃.
The Role Of The Diaphragm In Valves
The diaphragm is highly flexible and force to control the opening and closing of the valve. It primarily controls, obstruct or isolate the flow of fluids and acts as a flow control device.
Pay Attention:
◆ Please check whether the product is intact before use
◆ Please confirm that the installation conditions are in accordance with the specifications
◆ Please use in a stable environment
◆ Pay attention to clean up dust and other things that affect operation
