What is GPO-3 material? Applications of GPO-3. GPO-3 laminate is a novel electrical insulation material, also known as UPGM203, composed of alkali-free glass fibre mat impregnated with unsaturated polyester resin.

What is GPO-3 material? Applications of GPO-3. GPO3 laminate is a novel electrical insulation material, also known as UPGM203. It is a rigid insulating material formed by impregnating alkali-free glass fibre matt with unsaturated polyester paste, adding appropriate additives, and then hot-pressing. Hony Plastic specialises in manufacturing and supplying electrical insulation materials, including self-produced GPO3 insulating laminates. We also offer custom component machining according to client-specified drawings and dimensions. All our electrical insulation materials hold national UL certification and ROHS compliance reports, ensuring superior quality at competitive pricing.

GPO3 Electrical Insulation Material

Colours: Red, White, Brownish-Red

Full Sheet Specifications: 1200x1000x0.8-50mm

GPO3 Laminate Characteristics:

1. Arc resistance (exceeding 180 seconds)

2. Excellent tracking resistance (CTI 600V)

3. Temperature rating: 155°C

4. Flame retardancy: 94-V0 rating 5. High mechanisation and automation levels, ensuring stable product quality.

Applications of GPO-3 Laminated Board:

1. Circuit Breaker Applications

(1) Frame-type circuit breakers: Safety baffles, protective shields, compartment spacers, phase separators, etc.

(2) Applications in moulded-case circuit breakers: Phase separators, arc-extinguishing chamber separators, etc.

2. Motor and generator applications: Armature components, movable cover plates, slot wedge stators, stator shims, thin shims, carbon brush plates

3. Switchgear applications: Front, rear, top, bottom, and phase separators within partition systems

4. Suitable for switchgear partitions, liners, arc-extinguishing hoods, cylinders, plates, arc-isolating plates, terminal boards, phase insulation, base partitions, contact supports; structural supports for switches and transformers, busbar clamps, etc.

5. Arc-resistant structural components. DC motors

Our factory specialises in manufacturing and supplying electrical transformer insulation materials as follows:

1. GPO-3 unsaturated polyester laminates and profiles (U-channels, L-brackets, square tubes, round tubes, round rods, I-shaped supports, angle supports, flat strips)

2. SMC sheets, SMC insulators

3. Epoxy fibreglass cloth boards FR-4, FR-5, G10, G11 (epoxy fibreglass boards)

4. Phenolic flame-retardant Bakelite board FR-2

5. Machined transparent PC components, vulcanised fibreboard (Toyo Kaba paper), insulating paperboard

6. Melamine-faced panels (Bonded Melamine Board)
