Slewing Bearings: Characteristics, Processes, and Application Guidelines

Slewing bearings, also known as slewing rings, are large-sized bearings capable of simultaneously withstanding substantial axial loads, radial loads, and tilting moments. Below is an introduction to their product advantages, characteristics, manufacturing processes, and other aspects:

Product Advantages

High Load-Bearing Capacity: Designed to withstand combined loads, slewing bearings feature a robust structure that can bear heavy loads and adapt to complex mechanical environments, simultaneously enduring axial loads, radial loads, and tilting moments.

Compact Structure & Easy Installation: With a compact structural design, they reduce installation space requirements. Equipped with mounting holes and positioning structures, they facilitate integration with mechanical equipment and simplify the installation process.

Stable Rotation & High Precision: Utilizing rolling elements for motion, they achieve extremely stable rotation, reducing friction and vibration, which helps improve the operational precision and stability of mechanical devices.

Long Service Life & Low Maintenance: Typically adopting high-quality materials and advanced manufacturing processes, they possess excellent wear resistance and corrosion resistance. Sealing devices and lubrication systems also effectively extend their service life and lower maintenance costs.

Product Characteristics

Diversified Structures: Common types include single-row four-point contact ball, double-row different-diameter ball, single-row crossed roller, and three-row roller structures. For example, the single-row four-point contact ball type has a compact structure and light weight, capable of withstanding axial and radial forces simultaneously; the three-row roller type offers the highest load-bearing capacity.

Integrated Components: Generally composed of inner rings, outer rings, rolling elements, and separators. They may also be equipped with mounting holes, internal or external gear teeth, lubrication holes, and sealing devices.

High-Quality Materials: Rolling elements are usually made of fully hardened carbon-chromium bearing steel, such as GCr15 or GCr15SiMn steel; rings adopt surface-hardened steel, commonly 50Mn steel, and 42CrMo, 5CrMnMo, etc., can also be selected based on special requirements.

Manufacturing Processes

Raw Material Selection & Preparation: High-quality materials such as bearing steel are strictly selected and undergo rigorous inspection before entering the production line to ensure no cracks, folds, or other defects.

Forging & Heat Treatment: The basic shape of the bearing is formed through forging, followed by heat treatment processes like normalizing and tempering to improve the mechanical properties of the material.

Machining & Shaping: Including rough machining, finish machining, and raceway machining. Rough machining turns the workpiece into a shape close to the final size; finish machining further improves precision and surface finish; raceway machining undergoes rough grinding and fine grinding.

Processing of Rolling Elements & Cages: Rolling elements require precise grinding and polishing. Cages are designed and manufactured according to the type and quantity of rolling elements to ensure stable retention of rolling elements and reduce friction.

Quality Inspection & Assembly: Strict quality inspection is conducted at each production stage. During assembly, the fit and clearance of components must meet design requirements. After assembly, final inspections are carried out, including no-load slewing resistance moment testing and appearance inspection.

Slewing Bearing



Usage Methods

Proper Installation: Ensure the fit precision between the bearing, shaft, and bearing housing during installation, and adopt appropriate methods such as hot fitting or cold fitting. For toothed slewing bearings, attention should be paid to the gear meshing clearance.

Reasonable Lubrication: Select suitable grease or lubricating oil based on the bearing’s working conditions. Regularly check the lubrication status and replenish or replace grease in a timely manner. Generally, under high-temperature, high-speed, or heavy-load conditions, grease with good high-temperature resistance and anti-wear performance should be selected.

Regular Maintenance: Regularly monitor the bearing’s operating status, including temperature, vibration, and noise. Immediately shut down for inspection if any abnormalities are found. Meanwhile, clean and inspect the bearing regularly to check for defects such as wear, cracks, or spalling on raceways, rolling elements, cages, and other components.

Applicable Scope

Lifting & Transport Machinery: Such as wheeled cranes, crawler cranes, and portal cranes.

Construction Machinery: Including excavators, demolition machines, stacker-reclaimers, graders, and road rollers.

Port Machinery: Such as port cranes and reach stackers.

Wind Power Generation: Yaw bearings and pitch bearings of wind turbines usually adopt slewing bearings.

Medical Equipment: Large medical devices like gamma knives, CT scanners, and MRI machines also use slewing bearings.

Robotics: Installed at robot joints to achieve high-precision rotational motion.

Notes

Avoid Overloading: Although slewing bearings have high load-bearing capacity, overloading should still be avoided to prevent affecting their service life.

Prevent Foreign Matter Intrusion: Keep the bearing and bearing housing clean to prevent dust, debris, and other foreign matter from entering the bearing interior and interfering with normal operation.

Ensure Installation Precision: Strictly follow operational requirements during installation to ensure the bearing’s installation precision; otherwise, it may lead to unstable operation or premature damage of the bearing.

Packaging and Transportation

Packaging: Qualified slewing bearings are carefully packaged to prevent damage during transportation and storage. Packaging materials typically include anti-rust paper, plastic bags, and wooden packing boxes, providing adequate protection while facilitating transportation and handling.

Transportation: Avoid violent vibration and impact during transportation. Use special transport tools and fixing methods to ensure the stability of bearings during transit. Meanwhile, pay attention to the temperature and humidity of the transport environment to prevent bearings from being affected by moisture and high temperatures.
