Product Highlight：
1.Enables continuous automated processing of wires,including automatic cutting and stripping,terminal crimping on one end,and conductor twisting and tinning on the tail end.
2.Features a linear wire feeding and pulling mechanism,ensuring high precision,high speed,and minimal risk of wire damage,while also being easy to maintain.
3.Equipped with a precision modular cutter holder,guaranteeing superior quality in cutting,stripping,and conductor twisting.
4.Utilizes globally renowned brands for servo systems,pneumatic components,and linear guides,ensuring stable and reliable overall machine performance.
5.Incorporates a user-friendly touch-screen HMI(Human-Machine Interface)for convenient parameter adjustment and simple,flexible operation.
6.Suitable for electronic wires.Optional configurations allow for processing parallel wires/sheathed cables/ribbon cables.Additional options include wire separating,stranding,tail twisting,and bending,providing a wide application range to meet diverse product requirements.
Smart Terminal Crimping System | PLC-Controlled Processing with Real-Time Monitoring
Flexible Automatic Crimping Machine | Quick Changeover for Multiple Terminal Types
Automotive Terminal Crimper | IPC-Compliant Crimping for Automotive Wiring Harnesses
Experience end-to-end automation with our integrated solution featuring Wire Cutting Stripping Machine precision and automatic wire crimping machine reliability. This complete system, built around our flagship Automatic Terminal Crimping Machine, ensures consistent quality from stripped wire to perfectly crimped terminal, ready for immediate use in your Connector Assembly process.
Machine Main Specification：
|
Model |
JH-5505P fully automatic five line translation single head soldering machine |
|
Power Supply |
AC 220V |
|
Cutting Length |
30-800 mm (Customizable) |
|
Stripping Length |
0-10 mm |
|
Conductor Twist Length |
3-10 mm |
|
Tinning Length |
0.5-10 mm |
|
Wire Range |
AWG #32 - #18 |
|
Production Rate |
Number of input wires × 1000-1050 cycles/hour (wire length ≤200mm) |
|
Machine Dimensions (L×W×H) |
1800 × 900 × 2100 mm |
|
Weight |
365 kg |
