parameters of plastic bag roll making machine
Bag Width 400-600mm
Bag length 400-650mm
Bag making speed 60-150 PCS/MIN
Material thickness 0.006-0.05mm
Bag type drawstring bag on roll
Material HDPE, LDPE
Total power 20kw
Weight 6800kg
Size 10500*2100*1900mm
Operation and control: 7’’ HMI, PLC control
Main control motor: 2.2KW motor, with gear box
Bag making control: servo motor, 3 sets
Temp. control: 5-Zone, high and low temperature alarm and automatic stop
Unwind motor: AC 550W
Unwind loading: By pneumatic cylinder, and electric control
String width: max. 100mm
String unwind motor: AC 550W with inverter
Feeding motor: AC 550W*2
Inverter: AC 0.75KW
Any things about flexible package machinery you want to learn, please don't hesitate to contact with us. Our sales team has 15 years experience, can do very well no matter sales or after-sale.
