Product Description
Advantage and characteristics:
The pneumatic cylinder-type double clamping device of the German Durkopp model disperses the thread clamping pressure, effectively preventing knotting and twisting of the thread. The thread path is smooth, the stitch pattern is beautiful, and the thread breakage rate is reduced by more than 20%.
The guide rail is upgraded from 9 millimeters to a 15-millimeter high-precision version, and the number of guide rails on the Y-axis is increased from 2 to 4. The accuracy is improved by more than 90%,
the durability is enhanced by more than 50%, and the load-bearing capacity is increased by more than 80%.
The transmission belt is upgraded from a single imported belt to two belts, with a spacing of 30 centimeters, enabling them to exert force simultaneously.
The direct connection ratio of the motor is increased from 1:1 to 1:2.5, the power is enhanced by 70%, high-speed sewing is more precise, and the vibration and noise are reduced by 20%.
|
Sewing range |
200*100mm |
|
Max Speed |
200-2800rpm |
|
Stitching Pitch |
0.1-12.7mm |
|
Max.Stitching |
20000 stitchihnes/pattern |
|
Max number of patterns |
more than 1000 in car flash , external can in USB |
|
Hook |
Double size rotary hook |
|
Needle |
DP*17 14-25# |
|
Height of internal presser foot |
60mm |
|
Height of middle presser foot |
4-10mm |
|
Presser foot mode |
Air |
|
Volt |
AC . 220V |
|
Net weight |
145kg |
|
Gross weight |
210kg |
|
Size |
1200*1160*1360mm |
If you are interested in the product, contact 2bvideo.com for more information for more information
