Product details

Suitable for all types of asphalt mixes.

Minimizes both thermal and stress related reflective cracking.

Reduces pavement rutting under high ambient temperatures and intense wheel loads.

Increases the fatigue life of pavements with weak foundations.

Extends pavement life.

Provides cost benefits by increasing pavement life cycle.

Fast, easy installation and recyclable.

Reduces overlay thickness to a minimum of 50 mm.

Item	TGSG15-15	TGSG20-20	TGSG25-25	TGSG30-30	TGSG35-35	TGSG40-40	TGSG45-45
Longgitudinal Tensile strength ≥ (KN/m)	15	20	25	30	35	40	45
Transverse Tensile strength ≥ (KN/m)	15	20	25	30	35	40	45
Longitudunal Elongation ≤ (%)	15
Transverse Elongation ≤ (%)	13
Longitudinal Tensile strength at 2% strain ≥ (KN/m)	5	7	9	10.5	30	30	30
Transverse Tensile strength at 2% strain ≥ (KN/m)	5	7	9	10.5	30	30	30
Longitudinal Tensile strength at 5% strain ≥ (KN/m)	7	14	17	21	24	28	32
Transverse Tensile strength at 5% strain ≥ (KN/m)	7	14	17	21	24	28	32
Width ≤ (m)	6

photobank (1)

Feature:

● Increase the bearing capacity of the roadbed and foundation and prolong their service life.
● Prevent road surface and foundation from sinking or flawing, keep clean and beautiful ground surface.
● Convenient construction saves time and labor, reduce mounting time and decrease maintenance expense.
● Prevent culverts from flawing.

● Enhance earth slope and prevent water loss and soil erosion.

● Decrease underlayer thickness and save manufacturing cost.

● Enhance the stability of side slope turf net patch to improve greening.
● Replace wire netting used in mine as intermediate ceiling netting.

Product Application

Reinforced soil engineering

Reinforced soil retaining wall, steep slope and the reinforcement and consolidation of the soft ground.

Road construction

Ground treatment, reinforcement of the bridge abutment, reinforcement of the enbankment, reinforcement of the pile-net roadbed.

122

Irrigation projects
Protection of port, approach lane, seabeach, channel, river channel, dam and other irrigation projects.

Enviromental projects
Land reclamation, prevention and controlling of the desertification, and the composite protective structure in the landfill sites of urban garbage and waste.

123

Mine engineering
Coal mines, side slope protection of opencast mines, slope protection for the dumping site of the opencast mines,reinforcement to counter dam in the large tailing ponds of the metallurgical mines.

Soil engineering
Construction of stuffing and package system of heavy soil engineering.

124

Slope protection
Slope protection in the area affected by earthquake.

Dump leaching
Ground consolidation of large dump leaching and slag site.
