JH-2TD & JH-4TD Fully Automatic Single-Head Terminal Crimping Machines
Product Description:
The single-terminal crimping machine adopts modern frequency converter control technology, building upon the foundation of traditional silent terminal presses by integrating an automated vibratory bowl feeding system. It combines the established advantages of conventional terminal crimping with the high efficiency and low error rate of vibratory feeding, enabling a single machine to complete both the feeding and crimping processes autonomously.
The feeding system is equipped with an auxiliary detection system. When the material supply is sufficient, the sorting vibratory bowl automatically stops operating, thereby reducing energy consumption and minimizing operational noise. An integrated protective shield at the operator's station ensures personnel safety. This comprehensive protection system, coupled with user-friendly operation, achieves levels of precision, strength, and safety that are beyond the reach of standard machinery.
The Fully Automatic Single-Head Terminal Crimping Machine is a high-precision terminal crimping machine engineered for efficiency. As a reliable crimping machine for cable, it automates the full process from feeding to crimping. This integrated stripping and crimping machine ensures consistent, high-quality terminations in compact production setups.
Machine Main Specification：
|
Category |
JH-2TD |
JH-4TD |
|
Model |
JH-2TD Fully Automatic Single-Head Terminal Crimping Machine |
JH-4TD Fully Automatic Single-Head Terminal Crimping Machine |
|
Power Supply |
AC 220V 50/60Hz |
AC 220V 50/60Hz |
|
Motor Power |
750 W |
1100 W |
|
Standard Functions |
Single terminal automatic feeding and automatic crimping |
Single terminal automatic feeding and automatic crimping |
|
Production Rate |
~4,000 pieces/hour (depending on operator proficiency) |
~4,000 pieces/hour (depending on operator proficiency) |
|
Crimping Range |
0.5-6.0 mm² |
0.5-16.0 mm² |
|
Crimping Stroke |
30 mm |
30 mm |
|
Crimping Accuracy |
±0.03 mm |
±0.03 mm |
|
Crimping Force |
20 kN |
40 kN |
|
Machine Dimensions (W×L×H) |
500 × 860 × 1360 mm |
500 × 860 × 1440 mm |
|
Weight |
Approx. 130 kg |
Approx. 155 kg |
