Product details

Efficient range extender system: engine thermal efficiency of 45%; The highest efficiency of the motor is 97.44%, and the average efficiency of each power point is 95%, leading internationally

Ultra lightweight design: Lightweight cylinder head cover, oil pan, turbocharger intake pipe, all aluminum flywheel housing

Modular design: Machine cooling module and modular intake of air through the crankshaft

NVH: The surface sound pressure levels of the steady - state range extender at 20kW and 150kW power points are 70.5dBA and 90.2dBA, which are better than industry competitors

Ultra low fuel cost: adopting advanced technologies such as theoretical air - fuel ratio closed - loop control and multi - point fuel injection to optimize combustion, the engine has better fuel economy, low operating costs, and extremely high cost - effectiveness. Compared to diesel engines, it can save 40.2% in economy

High reliability: Adhere to the concept of high - quality development, from a technical perspective CAE analysis and experimental verification are considered from multiple dimensions to ensure reliable product quality, B10 has a lifespan of ≥ 1.5 million kilometers

Ultra low emissions: Methanol is recognized as a clean energy source. Compared to conventional fuels such as gasoline and diesel, methanol combustion is more complete and thorough, and its emissions include CO HC and NOx emissions have significantly decreased, with a reduction of ≥ 95%, achieving near zero emissions.

Engine performance parameters

Item	Unit	Parameter
Type	-	In-line,four-stroke,liquid-cooled,supercharged and intercooled
Rated power/speed	kW/rpm	180/2000
Maximum torque/speed	Nm/rpm	950/1200-1500
Maximum no-load speed	r/min	2200±50
Ider speed	r/min	700±50
Total piston displacement	L	5.91
*Number of cylinders- borestroke**	mm	4-112*150
Work order	-	1-3-4-2
Direction of rotation (from the fiywheel end)	-	Counterclockwise
Engine nameplate quality	kg	525（without oil or water）
Fuel type	-	Main fuel:M100 methanol Auxiliary starting fuel:92#gasoline No gasoline auxiliary starting device is used,and coolant heating is required to ensure engine starting
Exhaust temperature	℃	≤620
Range extender voltage platform	V	600
Range extender rated current	A	220
Range extender maximum power generation rate	kW	150
