Product details

H1: [FHG2400]

Plastic Injection Molding Machine for Efficient and Stable Mass Production

FUHONG [FHG2400] is a servo-driven plastic injection molding machine designed for manufacturers who need stable molding performance, accurate plasticizing, reliable clamping, and efficient long-term production. As an experienced injection molding machine manufacturer and supplier, FUHONG provides complete plastic processing solutions for customers worldwide.

This injection molding machine is suitable for producing a wide range of plastic products, including household items, industrial components, packaging products, caps, containers, fittings, and customized plastic parts.

Why Buyers Choose This Injection Molding Machine

1. Stable Clamping for Consistent Parts

The strong clamping structure ensures stable mold locking during injection, helping to improve product consistency, reduce flash, and support reliable continuous production.

2. Accurate Plasticizing and Injection Control

The injection unit delivers smooth plasticizing, accurate material control, and stable shot repeatability for better product appearance, dimensional accuracy, and production consistency.

3. Energy-Saving Servo Drive

The servo energy-saving system adjusts output according to actual production demand, reducing power consumption and supporting lower operating costs with quieter operation compared with traditional hydraulic systems.

4. Intelligent Control System

The user-friendly control interface simplifies machine operation, parameter setting, fault checking, and production monitoring for operators at all experience levels.

5. Customizable Machine Configuration

FUHONG offers configuration suggestions based on product weight, mold size, cavity number, plastic material, and production capacity, with optional configurations for different application needs.

Applications of This Injection Molding Machine

Plastic household products
Bottle caps and packaging components
Industrial plastic parts
Electrical appliance parts
Automotive plastic components
Plastic containers and fittings
Commodity plastic products
Customized injection molded parts

Why Choose FUHONG as Your Injection Molding Machine Supplier

Over 20 years of experience in injection molding machinery and mold manufacturing
Professional manufacturer of injection molding machines, molds, blow molding machines, and auxiliary equipment
Complete plastic processing solutions including mold support, auxiliary equipment suggestions, production line matching, and technical guidance
Machines supplied to customers in different countries and regions, with machine selection, configuration advice, installation guidance, operation training, and after-sales service
Focus on machine stability, production efficiency, maintenance convenience, and long-term value for B2B buyers

Not sure which injection molding machine model fits your products? FUHONG can analyze your product size, material, mold design, and expected output, then recommend a suitable solution.

Technical Specifications

Please add the actual parameters of each product model to this section.

ITEM		UNIT	FHG1800
Injection Unit	Screw Diameter	mm	45	50	52
	Screw L/D Ratio	L/D	22.5	20	19.1
	Shot Volume(Theoretical)	cm³	357	441	447
	Injection Weight(PS)	g	325	402	434
	Injection Rate	g/s	128	159	172
	Injection Pressure	Mpa	195	158	146
	Screw Speed	r/min	0-180
Clamping Unit	Clamping Force	KN	1800
	Toggle Stroke	mm	435
	Max. Mould Height	mm	540
	Min. Mould Height	Mm	200
	Space Between Tie-Bars	mm	480×480
	Ejector Stroke	mm	135
	Ejector Force	KN	53
Others	Max. Pump Pressure	Mpa	16
	Pump Motor Power	KW	22
	Heater Power	KW	12.4
	Machine Dimension(LWH)	m	5.03×1.33×1.70
	Machine Weight	Ton	5
	Oil Tank Capacity	L	180
