| Accuracy | 0.2%F·S or 0.5%F·S |
| Linearity | -0.1-60Mpa Optional, the minimum range is 0-10kpa |
| measurement range | 0.5%F·S |
| Temperature drift | ＜±0.75%F·S (0~50℃) |
| Long-term stability | ≤02.5F.S/ year |
| Esponse time | ≤10mS |
| Power supply | 12~36VDC |
| Qutput | 4~20mA、1~5V、0~5V、0~10V |
| Load Resistance | 0-60Ω (for 24VDC, 4-20mA two-wire system) |
| proof pressure | 1.5 times the maximum rated pressure |
| Output | 4…20mADC |
| Compensated Temperature | -20-85℃ (up to 300℃ or more with buffered heat pipes) |
| Storage temperature | -45~+125℃ |
| Ambient Temp | -20…85ºC |
| Pressure connection | Thread, flange, clamp can be customized |
| Mounting position | Unlimited |
| Protection | IP65 |
| Wetted parts | 304 or 316L stainless steel |
| Isolation diaphragm materia | 316L stainless steel (or Hastelloy C) |
| Power cosumption | < 0.5W(when the power supply is 24VDC |
