Gear Reducers for Kawasaki Main Engines: RG11, RG14, RG20, RG23, RG27 (Part of the M5X-RG Series)

These gear reducers integrate M5X series fixed-displacement motors with two-stage planetary reduction gears, offering high reliability and long service life. Below is a detailed introduction:

I. Technical Features

1. High Reliability: The two-stage planetary gear design ensures high reliability and extended service life.

2. Diverse Specifications: A variety of pinion specifications are available to meet different application requirements.

3. Integrated Design: The integration of M5X series fixed-displacement motors with reduction gears simplifies the system structure and improves transmission efficiency.

II. Models and Specifications

Here are the specific specifications for some models within the M5X-RG series:

【表格】

Model Reduction Ratio Total Displacement (cm³) Pressure (MPa) Maximum Speed (min⁻¹)

M5X80-RG06E 20.0 1580 54.8 115

M5X80-RG08E 20.0 1580 66 115

M5X130-RG12E 20.0 2590 122 92

M5X180-RG16E 20.0 3600 165 84

M5X180-RG23E 25.2 4540 234 67

M5X250-RG27D 25.2 6300 270 60

III. Application Fields

Kawasaki's RG series gear reducers are widely used in industrial sectors requiring high reliability and long service life, including:

1. Construction Machinery: Employed in hydraulic transmission systems of excavators, loaders, and other equipment.

2. Metallurgical Equipment: Utilized in hydraulic control systems of blast furnaces, converters, and other equipment.

3. Marine Machinery: Applied in hydraulic drive systems of ship steering gears, anchor winches, and other equipment.

4. Other Industrial Sectors: Such as petrochemical, power generation, environmental protection, and other industries with hydraulic transmission systems.
