4 PIECES AA Battery Holders SNAP TYPE

2 month ago

0 0

HuiZhou Antenk Electronics Co., LTD

 5 year year

Product details

Huizhou Antenk Electronics Co., Ltd. (IATF16949, ISO9001, ISO14001 certified) presents the 4 AA Battery Holders Snap Type, designed for quick tool‑free battery installation. This holder accepts four AA (LR6) cells in series, delivering 6V output. The housing is molded from UL94 V-0 rated PBT or glass‑filled nylon, featuring integrated snap‑fit battery latches that provide audible click feedback when cells are fully seated. Contacts are nickel‑plated phosphor bronze (positive) and pre‑loaded coil springs (negative), rated for 3A continuous. Key specs: contact resistance <30mΩ, operating temperature -20°C to +70°C, retention force 150–200g per cell. Available with 150mm wire leads (red/black) or PCB solder tabs. RoHS, REACH, UL (E472792) compliant.

Applications: portable lighting, medical monitors, handheld instruments, children’s toys, backup power, and DIY electronics. Usage: insert each AA battery positive‑end first into the snap‑type retainer; the latch engages with a click. To remove, depress the latch and lift the battery. Connect wires or solder tabs to your circuit. Precautions: do not mix old/new batteries, avoid reverse polarity, max 3A. Advantages over competitors: Antenk’s snap latches prevent battery dislodgement under vibration (tested 5G), while competitive slide‑type holders often allow movement. Wide contact surfaces minimize voltage drop. Low MOQs (1,000 units), no tooling fees for standard wire lengths.

Production: mold design → injection molding (10 Japan/Taiwan machines) → stamping contacts (9 presses) → plating (Ni) → spring coiling → manual/semi‑auto assembly → wire soldering → 100% continuity & polarity test → 48h salt spray test → final QC. Free samples, drawings, 24h support. Contact Antenk.

NOTES:

1、HOLDER MATERIAL:POLYPROPYLENE.

2、SPRING MATERIAL:MUSIC WIRE,0.7DIA

FINISH:NICKEL PLATED

3、SNAP-ON TERMINAL MATERIAL: BRASS,NICKEL PLATE
