MYJG-150 150W CO2 laser power supply

Basic Info.

Brand：ZYE

Input Voltage AC：220V/ AC110V

AC Frequency ：47~440HZ

Max Output Voltage： 34KV

Max Output Current ：38mA(Depends on Laser tube)

Efficiency：91%

Cooling：Fan Cooling

Over Current Protection：130% of Max.Current

Working Temperature：-30 - +65 Degree Centigrade

Humidity：20-85%RH(No Dew)

Output-Shell：Connected

Insulation：Not Less Than 50MOHM（DC500V）

Leakage Current：Not Less Than 1mA（AC220V）Not More Than 0.5 mA（AC110V）

Shock Resistance：Amplitude: 0.5mm, Frequecy:10-55Hz, 3D Dretion:2 Hours

MTBF：Not Less Than30,000hours

Full Load 60 Degree Centigrade test：12Hours

7 Seconds Start/Stop Test：500 Times

Withstand Voltage

Input-Output：AC1500V/MinNot More Than10mA

Input-Shell：AC1500V/MinNot More Than10mA

Open circuit ProtectionYes (For short time)

Voltage Range of High Level Control：Not Less Than3V

Voltage Range of Low Level Control：Not More Than0.8V

Dimensions (mm)：305*161*96

Weight (kg)：3.6

Color：Black

FeatureS:(optional LCD Display)

1.Good compatibility: lt can be applicable to 100W,120W,130W,150W laser tubes manufactured by different factories.

2、High Voltage Power Supply: Input AC 220V or AC 110V Voltage ,Max output DC 50KV.

3、High efficiency, high frequency, and fast response for CO2 lasers.

4、Easy to control, suitable for high-level or low-level signals

5、an be controlled via either a 0 to 5V analog signal or a PWM signal to precisely regulate the laser output power.
