This efficient spiral press is functional Material handling equipment and robust Heavy-duty industrial material transfer machinery, serving as specialized Industrial bulk solid conveying machine and matched Wastewater sludge handling conveyor auxiliary unit, also high-efficiency Automatic slag transporting equipment focusing on grid residue dewatering and volume reduction after bar screen conveyor inside sewage treatment plants and pump stations. Model LYZ is designed with central shaft spiral structure and fixed 45° upturned layout, whole stainless steel construction integrates conveying and squeezing dewatering into one process to cut grid slag moisture content effectively for subsequent solid waste disposal.
Applicable Site: Grid residue dewatering after slag conveyor of municipal sewage plant and pump station; Standard specification range:LYZ200~LYZ300; Effective squeezing length:1m~3m; Fixed upturned installation angle:45°; Core function: grid slag squeezing dewatering and volume reduction; Blade type: central shaft driven spiral; Whole machine material: full stainless steel; Regular type composition: drive unit, base frame, feed hopper, drainage grid, water outlet trough, spiral shaft, barrel and slag discharge pipe; High drainage version extra parts: feeding bin, discharge device, spiral pressing zone, independent drainage area and top cover assembly; Working principle: raw slag enters from top inlet, spiral blade pushes material for gradual compression, separated filtrate drains out via bottom holes while dewatered solid discharges from end slag tube.
Custom non-standard cylinder diameter beyond LYZ200-300 standard size; tailor single machine squeezing length within 1~3m range for special slag processing capacity of customized Wastewater sludge handling conveyor matched Material handling equipment; adjust spiral compression pitch according to incoming slag initial moisture to optimize dewatering efficiency of Automatic slag transporting equipment; upgrade high-drainage enhanced structure for high-water-content raw slag of customized Industrial bulk solid conveying machine supporting system; modify feed inlet dimension to realize seamless docking with front-end different specification Heavy-duty industrial material transfer machinery slag delivery conveyor.
If you are interested in the product, contact 2bvideo.com for more information for more information
