Product details

Mainly applied by pharmaceutical, chemical and foodstuff industry etc to make granules.

GMP design; suitable to large ,medium or small batch production.

Roller granulator uses the crystal water of the material itself and relies on the principle of mechanical extrusion to directly extrude the dry powder raw materials into flakes, then the flakes are roughly crushed and granulated .In the granulation process ,the raw powders do not need to add adhesive and water.

The equipment that we have produced Granulator Machine; Drying Machine; Mixing Machine; Pulverizer; Sifter; Converyor；such as High Speed Mixer Machine；Powder Screening Vibratory Shaker；Swing Drum Blender；Pharmaceutical Bolling Granulating Dryer；Vibration Fluid Bed Dryer；high speed mixing granulator；screw extrude granulator；wet material rotary granulator；Customers can choose the appropriate products according to their own needs.

型号Model	DG30	DG60	DG80	DG100	DG120	DG200
压轮直径Roller Diameter(mm)	Ø70	Ø120	Ø120	Ø240	Ø240	Ø360
产量Capacity (kg/h)	1-8	3-30	15-60	30-80	60-120	100-250
挤压功率Press Motor Power (kw)	2.2	2.2	3	5.5	7.5	11
加料功率Feed Motor Power (kw)	1.1	1.1	1.5	2.2	3	5.5
制粒功率Granulating Motor Power (kw)	0.75	0.75	1.1	2.2	3	5.5
加料搅拌功率Feed Mixing Motor Power (kw)	---	---	0.75	0.75	0.75	0.75
油泵功率Oil Pump Motor Power (kw)	0.75	0.75	0.75	0.75	0.75	0.75
对辊转速Roller Rotate Speed (rpm)	0-33	0-33	0-33	0-33	0-33	0-33
加料速度Feed Speed rpm)	0-80	0-80	0-80	0-80	0-80	0-80
液压压力Pressure Of Hydraulic Oil(Mpa)	≤28	≤28	≤28	≤28	≤28	≤28
