Specification: CG series Hydraulic Cylinder, double acting mill cylinder, ISO 6022 hydraulic cylinder, heavy duty round body cylinder
Manufactured in accordance with ISO 6022 and DIN 24333 heavy-duty industrial standards.
Bore 63mm / Rod 45mm / Stroke 70mm.
Rated working pressure 250 Bar (25 MPa); Maximum static test pressure 375 Bar.
MT4 Intermediate Trunnion Mounting: Provides superior pivot stability and load balancing, reducing side-load wear on seals.
Protective Bellows (Boot): Equipped with high-durability shielding to protect the piston rod from dust, debris, and contaminants in harsh mill environments.
Piston rod made of high-tensile C45 steel, induction hardened and hard chrome plated (30-50μm, Ra ≤ 0.4μm).
100% Interchangeable with Rexroth CDH1, Parker, and Eaton heavy-duty mill-type series.
Heavy-duty bolted flange design allows for rapid field maintenance and exceptional shock resistance.
| Item | Specifications |
| Model | CDH1 MT4 63/45-70 |
| Series | CDH1 Heavy Duty Mill Type |
| Standard | ISO 6022 / DIN 24333 |
| Bore Diameter | 63 mm |
| Rod Diameter | 45 mm |
| Stroke | 70 mm |
| Mounting Style | MT4 (Intermediate Trunnion Mounting) |
| Special Feature | Protective Bellows (Rod Boot) |
| Nominal Pressure | 250 Bar (25 MPa) |
| Rod Material | C45 Steel (Hard Chrome Plated) |
| Sealing System | High-Pressure Multi-lip NBR/Viton |
