S5 series In-line flexographic printing machine

3 week ago

0 0

GUANGDONG QIANRUN MACHINERY SCI&TECH CO.,LTD

 3 week year

Product details

1.The whole machine adopts the latest servo control system. Each printing unit is driven by an independent servo motor. The 8-color machine has a total of 27 servo motors to ensure accurate registration during high-speed operation.

2.Adopting a new petal-shaped structure and scraper system, it improves the common drawbacks of flexographic printing machines:

②lmproved the issues of in misting and “meteor shower” effects during high-speed flexo printing,as well as ink overflow and splashing on the edge of the anilox roller.

②Only the amount of ink used in a "single cup" can be used to start proofing, which no waste of ink, saving costs.as well as provide greater flexibility and efficiency for printing factory.

3.Printing or ink transfer pressure adjustment is quick and convenient: the printing roller adopts load-bearing type, and there is no need to adjust the pressure when changing the roller. At most, fine-tuning is required for special operations.

4.Intelligent non-stop system: optional this system, support manual/automatic paper connection, improve production efficiency; full visual automatic overprinting system, realize automatic overprinting and data storage, and can be retrieved with one button when returning the order, and automatically register.

5.Multifunctional printing: mainly flexographic printing, supporting cold stamping, lamination, Glue removal, multi-layer labels, folding labels, online inspection, die-cutting and other processes, and optional online screen printing, inkjet printing, gravure, etc.

机型 Type	370/450/550
色组可选Print color	2-12 Colors
最大印刷宽度 Max print width	370mm/450mm/550mm
印刷长度范围 Print repeat length	203.2-635mm
最大走纸宽度 Max. Web Width	380mm/460mm/560mm
机械速度 Max mechanical speed	200m/min
最大放卷直径 Max.Unwind Dia	ø1000mm
最大收卷直径 Max. Rewind Dia	ø1000mm
干燥系统 Drying system	Optional UV mercury lamp, LED UV, Hot air drying
